• Click Chassis Overview. The Chassis Health page displays a graphical overview of all the servers installed in the chassis. Server health
status is indicated by the overlay of the server subgraphic. For more information about the chassis health, see the Online Help.
• Click Chassis Overview > Server Overview. The Servers Status page provides an overview of the servers in the chassis. For more
information, see the Online Help.
Viewing Health Status and Information for Individual
Server
To view health status for individual servers, do any of the following:
1 Go to Chassis Overview > Properties > Health.
The Chassis Health page displays a graphical overview of all the servers installed in the chassis. Server health status is indicated by
the overlay of the server subgraphic. Move the cursor to hover over an individual server subgraphic. A corresponding text hint or
screen tip provides additional information for that server. Click the server subgraphic to view the I/O Module information on the right.
For more information, see the Online Help.
2 Go to Chassis Overview and expand Server Overview in the left pane. All the servers (1–4) appear in the expanded list. Click the
server (slot) you want to view.
The Server Status page (separate from the Servers Status page) provides the health status of the server in the chassis and a launch
point to the iDRAC web interface, which is the rmware used to manage the server. For more information, see the Online Help.
NOTE: To use the iDRAC web interface, you must have an iDRAC user name and password. For more information about
iDRAC and the using the iDRAC web interface, see the
Integrated Dell Remote Access Controller User’s Guide
.
Viewing Information and Health Status of the IOM
To view health status of the IOMs, in the CMC Web interface, do any of the following:
1 Click Chassis Overview.
The Chassis Health page is displayed. The graphics in the left pane displays the rear, front, and side view of the chassis and contains
the health status for the IOM. IOM health status is indicated by the overlay of the IOM sub-graphic. Move the cursor over the
individual IOM sub-graphic. The text hint provides additional information about that IOM. Click the IOM sub-graphic to view the IOM
information in the right pane.
2 Go to Chassis Overview > I/O Module Overview.
The I/O Module Status page provides an overview of IOM associated with the chassis. For more information, see the Online Help.
NOTE
: After updating or power cycling the IOM/IOA, make sure that the operating system of the IOM/IOA is also booted
correctly. Else, the IOM status is displayed as "Oine".
Viewing Information and Health Status of Fans
CMC controls the speed of the chassis fan by increasing or decreasing the fan speed on the basis of system events. You can run the fan in
three modes such as Low, Medium, and High. For more information about conguring a fan, see the Online Help.
To set up the properties of fans by using RACADM commands, type the following command at the CLI interface.
racadm fanoffset [-s <off|low|medium|high>]
For more information about the RACADM commands, see the Chassis Management Controller for PowerEdge VRTX RACADM Command
Line Reference Guide available at dell.com/cmcmanuals.
NOTE
: The CMC monitors the temperature sensors in the chassis and automatically adjust the fan speed as needed. However,
you can override to maintain a minimum fan speed by the racadm fanoset command. When overriden using this command, the
CMC will always run the fan to the selected speed even though the chassis does not require the fans to run at that speed.
CMC generates an alert and increases the fan speeds when the following events occur:
• CMC ambient temperature threshold is exceeded.
76
Viewing Chassis Information and Monitoring Chassis and Component Health
