About Your System 25
PCIe Degraded Link
Width Error:
Embedded
Bus#
nn
/Dev#
nn
/Func
n
Expected Link Width
is
n
Actual Link Width
is
n
Faulty or improperly
installed PCIe card.
Reseat the PCIe cards. See
"Expansion Cards" on
page 75. If the problem
persists, see "Getting Help"
on page 127.
PCIe Degraded Link
Width Error: Slot
n
Expected Link Width
is
n
Actual Link Width
is
n
Faulty or improperly
installed PCIe card in the
specified slot number.
Reseat the PCIe card in the
specified slot number. See
"Expansion Cards" on
page 75. If the problem
persists, see "Getting Help"
on page 127.
PCIe Training
Error: Embedded
Bus#
nn
/Dev#
nn
/Func
n
Faulty or improperly
installed PCIe card.
Reseat the PCIe cards. See
"Expansion Cards" on
page 75. If the problem
persists, see "Getting Help"
on page 127.
PCIe Training
Error: Slot
n
Faulty or improperly
installed PCIe card in the
specified slot number.
Reseat the PCIe card in the
specified slot number. See
"Expansion Cards" on
page 75. If the problem
persists, see "Getting Help"
on page 127.
Table 1-4. System Messages (continued)
Message Causes Corrective Actions
