set qos-group 5
police cir 300 pir 300
After upgrade to release 10.4.2, the policy configuration appears as follows:
policy-map type control-plane test
!
class test_Remapped_0
set qos-group 0
police cir 300 pir 300
!
class test_Remapped_5
set qos-group 5
police cir 300 pir 300
!
class test_Remapped_6
set qos-group 6
police cir 300 pir 300
In release 10.4.2, ARP_REQ is mapped to queue 6, ICMPV6_RS and ICMPV6_NS are mapped to queue 5, and ISCSI is
mapped to queue 0.
By default, CoPP traffic towards the CPU is classified into different queues as shown below.
Table 85. CoPP: Protocol mappings to queues - prior to release 10.4.2
Queue Protocol
0 IPv6
1
—
2 IGMP
3 VLT, NDS
4 ICMPv6, ICMPv4
5 ARP Request, ICMPV6-RS-NS, ISCSI snooping, ISCSI-COS
6 ICMPv6-RA-NA, SSH, TELNET, TACACS, NTP, FTP
7 RSTP,PVST, MSTP,LACP
8 Dot1X,LLDP, FCOE-FPORT
9 BGPv4, OSPFv6
10 DHCPv6, DHCPv4, VRRP
11 OSPF Hello, OpenFlow
The following table lists the CoPP protocol mappings to queues, and default rate limits and buffer sizes on the S4148FE-ON platform. The
number of control-plane queues is dependent on the hardware platform.
Table 86. CoPP: Protocol mappings to queues, and default rate limits and buffer sizes - from release 10.4.2 and later
Queue Protocols Minimum rate
limit (in pps)
Maximum rate
limit (in pps)
Minimum
guaranteed
buffer (in bytes)
Static shared
limit (in bytes)
0 Unresolved, iSCSI, IPv6 600 600 1664 20800
1 SFlow 1000 1000 1664 20800
2 IGMP, MLD, PIM control 400 400 1664 48880
