View configuration
Use show commands to display the protocol traffic assigned to each control-plane queue and the current rate-limit applied to each queue.
Use the show command output to verify the CoPP configuration.
View CoPP configuration
OS10# show qos control-plane
Service-policy (input): example-copp-policy-map-name
View CMAP1 configuration
OS10# show class-map type control-plane example-copp-class-map-name
Class-map (control-plane): example-copp-class-map-name (match-any)
View CoPP service-policy
OS10# show policy-map type control-plane
Service-policy(control-plane) input: example-copp-policy-map-name
Class-map (control-plane): example-copp-class-map-name
set qos-group 2
police cir 100 bc 100 pir 100 be 100
View CoPP information
OS10# show control-plane info
Queue Min Rate Limit(in pps) Max Rate Limit(in pps)
Protocols
0 600 600 ISCSI UNKNOWN UNICAST
1 1000 1000 SFLOW
2 400 400 IGMP MLD PIM
3 600 1000 VLT NDS
4 500 1000 IPV6_ICMP IPV4_ICMP
5 500 1000 ICMPV6_RS ICMPV6_NS ICMPV6_RA ICMPV6_NA
6 500 1000 ARP_REQ SERVICEABILITY
7 500 1000 ARP_RESP
8 500 500 SSH TELNET TACACS NTP FTP
9 600 600 FCOE
10 600 1000 LACP
11 400 400 RSTP PVST MSTP
12 500 500 DOT1X LLDP
13 600 1000 IPV6_OSPF IPV4_OSPF
14 600 1000 OSPF_HELLO
15 600 1000 BGP
16 500 500 IPV6_DHCP IPV4_DHCP
17 600 1000 VRRP
18 700 700 BFD
19 700 1000 OPEN_FLOW REMOTE CPS
20 300 300 MCAST DATA
21 100 100 ACL LOGGING
22 300 300 MCAST KNOWN DATA
View CoPP statistics
OS10# show control-plane statistics
Queue Packets Bytes Dropped Packets Dropped
Bytes
0 26 1768 0 0
1 0 0 0 0
2 0 0 0 0
3 0 0 0 0
4 36 3816 0 0
5 36 3096 0 0
6 919 58816 0 0
7 67 4288 0 0
8 0 0 0 0
9 0 0 0 0
10 0 0 0 0
11 80662 5539376 0 0
12 2779 462189 0 0
