View class-map
OS10(conf-cmap-queuing)# do show class-map
Class-map (queuing): example-que-cmap-name
Match: queue 5
View policy-map
OS10(conf-pmap-c-que)# do show policy-map
Service-policy (queuing) output: example-que-pmap-name
Class-map (queuing): example-que-cmap-name
bandwidth percent 80
Strict priority queuing
OS10 uses queues for egress QoS policy types. Enable strict priority to dequeue all packets from the assigned queue before servicing any
other queues. When you assign more than one queue strict priority, the highest number queue receives the highest priority. You can
configure strict priority to any number of queues. By default, all queues schedule traffic per WDRR.
Use the priority command to assign the priority to a single unicast queue—this configuration supersedes the bandwidth percent
configuration. A queue with priority enabled can starve other queues for the same egress interface.
Create class-map
1. Create a class-map and configure a name for the class-map in CONFIGURATION mode.
class-map type queuing class-map-name
2. Configure a match criteria in CLASS-MAP mode.
match queue queue-id
Define a policy-map
1. Define a policy-map and create a policy-map name CONFIGURATION mode.
policy-map type queuing policy-map-name
2. Create a queuing class and configure a name for the policy-map in POLICY-MAP mode.
class class-map-name
3. Set the scheduler as strict priority in POLICY-MAP-CLASS-MAP mode.
priority
Apply policy-map
1. Apply the policy-map to the interface in INTERFACE mode or all interfaces in SYSTEM-QOS mode.
system qos
OR
interface ethernet node/slot/port[:subport]
2. Enter the output service-policy in SYSTEM-QOS mode or INTERFACE mode.
service-policy {output} type {queuing} policy-map-name
Enable strict priority on class-map and apply the policy-map globally
OS10(config)# class-map type queuing example-cmap-strictpriority
OS10(config-cmap-queuing)# match queue 7
OS10(config-cmap-queuing)# exit
OS10(config)# policy-map type queuing example-pmap-strictpriority
OS10(config-pmap-queuing)# class example-cmap-strictpriority
OS10(config-pmap-c-que)# priority
