show qos ingress buffers interface
Displays interface buffer configurations.
Syntax
show qos ingress buffers interface [interface node/slot/port[:subport]]
Parameters
• interface — (Optional) Enter the interface type.
• node/slot/port[:subport] — (Optional) Enter the port information.
Default Not configured
Command Mode EXEC
Usage Information None
Example
OS10(config)# show qos ingress buffer interface ethernet 1/1/1
Interface ethernet 1/1/1
Speed 40G
-----------------------------------------------------------------------
PG# PRIORITIES qos ALLOTED (Kb)
group Reserved Shared buffer XOFF XON shared
buffer
id buffers MODE threshold threshold
threshold
-----------------------------------------------------------------------
0 4 4 35 DYNAMIC 9 9 8
1 3 3 35 DYNAMIC 9 9 8
2 - - 0 STATIC 0 0 0
3 - - 0 STATIC 0 0 0
4 - - 0 STATIC 0 0 0
5 - - 0 STATIC 0 0 0
6 - - 0 STATIC 0 0 0
7 - 0-2,5-7 8 STATIC 0 0 0
Supported
Releases
10.3.0E or later
show qos ingress buffer-statistics-tracking
Displays ingress priority group level peak buffer usage count in bytes for the given priority group on a given interface.
Syntax
show qos ingress buffer-statistics-tracking interface ethernet [node/slot/port]
[priority-group {0-7}] [detail]
Parameters
• node/slot/port—Enter the port information.
• [priority-group {0-7}]—Enter the priority-group keyword, followed by the group number.
• detail—Displays per MMU instance-level statistics in platforms with multiple MMU instances such as the
Z9100-ON series, Z9200-ON series, and MX9116n.
Default Not applicable
Command Mode EXEC
Usage Information When BST is enabled, if you make any configuration changes that affect the priority group or priority mapping
configuration, such as removal of class map, addition of class map to policy map (nqos), and so on, be sure to
clear the buffer statistics using the clear qos statistics type buffer-statistics-tracking
command to view the actual peak buffer utilization for the current configuration.
Example
OS10# show qos ingress buffer-statistics-tracking interface ethernet 1/1/1
Interface : ethernet1/1/1
Speed : 0
Priority Peak shared Peak HDRM
Group buffers buffers
------------------------------------------------
0 0 0
1 0 0
2 0 0
