Users Guide

Total shared lossy buffers - 11192
Total used shared lossy buffers - 0
OS10# show qos system egress buffer
All values are in kb
Total buffers - 12187
Total lossless buffers - 0
Total shared lossless buffers - 0
Total used shared lossless buffers -
Total lossy buffers - 11567
Total shared lossy buffers - 9812
Total used shared lossy buffers - 0
Total CPU buffers - 620
Total shared CPU buffers - 558
Total used shared CPU buffers - 0
View PFC ingress buffer statistics
OS10(config)# show qos ingress buffer-stats interface ethernet 1/1/15
Interface : ethernet1/1/15
Speed : 10G
Priority Used reserved Used shared Used HDRM
Group buffers buffers buffers
------------------------------------------------
0 9360 681824 35984
1 0 0 0
2 0 0 0
3 0 0 0
4 0 0 0
5 0 0 0
6 0 0 0
7 0 0 0
PFC commands
pause
Configures the ingress buffer and pause frame settings that are used for PFC traffic classes.
Syntax
pause [buffer-size kilobytes pause-threshold kilobytes resume-threshold
kilobytes]
Parameters
• buffer-size kilobytes — Enter the reserved (guaranteed) ingress-buffer size in kilobytes for PFC
dot1p traffic, from 0 to 7787.
• pause-threshold kilobytes — Enter the threshold used to send pause frames in kilobytes to a
transmitting device, from 0 to 7787.
• resume-threshold kilobytes — Enter the threshold used to request a transmitting device in kilobytes
to resume sending traffic, from 0 to 7787.
Defaults
The default ingress-buffer size reserved for PFC traffic classes, and the pause and resume thresholds, vary
according to the interface type. The default egress buffer that is reserved for PFC traffic classes is 0 on all
interface types.
Table 95. Port defaults
Port Speed 10G Port 25G Port 40G Port 50G Port 100G Port
PFC reserved
ingress buffer
45 KB 54 KB 93 KB 111 KB 178 KB
PFC pause threshold 9 KB 9 KB 18 KB 18 KB 36 KB
PFC resume
threshold
9 KB 9 KB 9 KB 9 KB 9 KB
1220 Converged data center services
