Default Not configured
Command Mode EXEC
Usage Information
• (none) — One or more of the following symbols displays:
• * — Synchronized to this peer.
• # — Almost synchronized to this peer.
• + — Peer was selected for possible synchronization.
• - — Peer is a candidate for selection.
• ~ — Peer is statically configured.
•
remote — Remote IP address of the NTP peer.
• ref clock — IP address of the remote peer reference clock.
• st — Peer stratum, the number of hops away from the external time source. 16 means that the NTP peer
cannot reach the time source.
• when — Last time the device received an NTP packet.
• poll — Polling interval in seconds.
• reach — Reachability to the peer in octal bitstream.
• delay — Time interval or delay for a packet to complete a round-trip to the NTP time source in milliseconds.
• offset — Relative time of the NTP peer’s clock to the network device clock in milliseconds.
• disp — Dispersion.
Supported on the MX9116n and MX5108n switches in Full Switch mode starting in release 10.4.0E(R3S). Also
supported in SmartFabric mode starting in release 10.5.0.1
Example
OS10# show ntp associations
remote ref clock st when poll reach delay offset disp
=============================================================
10.10.120.5 0.0.0.0 16 - 256 0 0.00 0.000 16000.0
*172.16.1.33 127.127.1.0 11 6 16 377 -0.08 -1499.9 104.16
172.31.1.33 0.0.0.0 16 - 256 0 0.00 0.000 16000.0
192.200.0.2 0.0.0.0 16 - 256 0 0.00 0.000 16000.0
OS10# show ntp associations vrf management
remote local st poll reach delay offset disp
=======================================================================
*1.1.1.2 1.1.1.1 3 64 1 0.00027 0.000056 0.43309
Supported
Releases
10.2.0E or later
show ntp status
Displays NTP configuration information.
Syntax
show ntp status [vrf {management | vrf vrf-name]
Parameters
• status — (Optional) View the NTP status.
• vrf management — (Optional) Enter the keywords to display NTP information corresponding to the
management VRF.
• vrf vrf-name — (Optional) Enter the keyword then the name of the VRF to display NTP information
corresponding to that non-default VRF.
Default Not configured
Command Mode EXEC
Usage Information
Supported on the MX9116n and MX5108n switches in Full Switch mode starting in release 10.4.0E(R3S). Also
supported in SmartFabric mode starting in release 10.5.0.1
Example (Status)
OS10# show ntp status
system peer: 0.0.0.0
system peer mode: unspec
