Users Guide

Parameters
• vlan vlan-id—Enter the VLAN ID. The range is from 1 to 4093.
Defaults None
Command Mode EXEC
Usage Information The dynamically learned entries are displayed as D and statically configured entries are displayed as S.
Example
OS10# show ip dhcp snooping binding
Codes : S - Static D – Dynamic
IPv4 Address MAC Address Expires(Sec) Type Interface VLAN
=========================================================================
10.1.1.22 11:22:11:22:11:22 120331 S ethernet1/1/4 100
10.1.1.44 11:22:11:22:11:23 120331 S port-channel100 200
10.1.1.5 11:22:11:22:11:24 120331 D ethernet1/1/5:4 300
Supported
Releases
10.5.0 or later
DNS commands
OS10 supports the configuration of a DNS host and domain parameters.
ip domain-list
Adds a domain name to the DNS list.
Syntax
ip domain-list [vrf vrf-name] [server-name] name
Parameters
• vrf vrf-name — (Optional) Enter vrf and then the name of the VRF to add a domain name to the DNS
list corresponding to that VRF.
• server-name — (Optional) Enter the server name to add a domain name to the DNS list.
• name — Enter the name of the domain to append to the DNS list.
Default Not configured
Command Mode CONFIGURATION
Usage Information There is a maximum of six domain names in the DNS list. Use the ip domain-list command to configure a
domain name to complete unqualified host names. The domain name appends to incomplete host names in DNS
requests. The no version of this command removes a domain name from the DNS list.
Example
OS10(config)# ip domain-list jay dell.com
Supported
Releases
10.2.0E or later
ip domain-name
Configures the default domain and appends to incomplete DNS requests.
Syntax
ip domain-name [vrf vrf-name] server-name
Parameters
• vrf vrf-name — (Optional) Enter vrf and then the name of the VRF to configure the domain
corresponding to that VRF.
• server-name — (Optional) Enter the server name the default domain uses.
Default Not configured
Command Mode CONFIGURATION
System management 213
