• 100g-1x — Reset a port to 100GE mode.
• 40g-1x — Set a port to 40GE mode for use with a QSFP+ 40GE transceiver.
• 25g-4x — Split a port into four 25GE interfaces.
• 10g-4x — Split a port into four 10GE interfaces.
4. Return to CONFIGURATION mode.
exit
5. Enter Ethernet Interface mode to configure other settings. Enter a single interface, a hyphen-separated range, or multiple interfaces
separated by commas.
interface ethernet node/slot/port[:subport]
Configure restricted port-group profile
OS10(config)# port-group 1/1/2
OS10(conf-pg-1/1/2)# profile restricted
OS10(conf-pg-1/1/2)# port 1/1/3 mode Eth 25g-4x
OS10(conf-pg-1/1/2)# exit
OS10(config)# interface ethernet 1/1/3:2
OS10(conf-if-eth1/1/3:2)#
View the interface
OS10(config)# interface ethernet 1/1/3:2
OS10(conf-if-eth1/1/3:2)# show configuration
!
interface ethernet1/1/3:2
no shutdown
Port-groups on S5200F-ON switches
On the S5200F-ON series switches, port-groups determine the available front-panel Ethernet ports and supported breakout interfaces.
When you convert a port to a particular mode, all ports that belong to the port group also operate at the same mode. For example, if you
convert the Ethernet 1/1/1 interface to 10g-4x, all other interfaces that belong to port-group 1/1/1 namely, 1/1/2, 1/1/3, and 1/1/4 also
operate at 10g-4x mode.
The following shows the supported port groups and breakout modes on the S5212F-ON switch:
OS10# show port-group
Port-group Mode Ports FEM
port-group1/1/1 Eth 10g-4x 1 2 3 4 -
port-group1/1/2 Eth 10g-4x 5 6 7 8 -
port-group1/1/3 Eth 10g-4x 9 10 11 12 -
port-group1/1/4 Eth 100g-1x 13 -
port-group1/1/5 Eth 100g-1x 14 -
port-group1/1/6 Eth 100g-1x 15 -
Table 22. Port groups and breakout modes on the S5212F-ON switch
Port Group Ports Supported breakout modes
Port-group1/1/1 1, 2, 3, 4
• 25g-4x
• 10g-4x
Port-group1/1/2 5, 6, 7, 8
• 25g-4x
• 10g-4x
Port-group1/1/3 9, 10, 11, 12
• 25g-4x
• 10g-4x
Port-group1/1/4 13
• 100g-1x
