2. Activate the unified port group for FC operation in PORT-GROUP mode. The available FC modes depend on the switch.
mode fc {32g-4x | 32g-2x | 32g-1x | 16g-4x}
• 16g-4x — Split a unified port group into four 16 GFC interfaces.
• 32g-1x — Split a unified port group into one 32 GFC interface. A 1x-32G interface has a rate limit of 28G.
• 32g-2x — Split a unified port group into two 32 GFC interfaces.
• 32g-4x — Split a unified port group into four 32 GFC interfaces. Each 4x-32GE breakout interface has a rate limit of 25G.
3. Return to CONFIGURATION mode.
exit
4. Enter FC Interface mode to enable data transmission. Enter a single interface, a hyphen-separated range, or multiple interfaces
separated by commas.
interface fibrechannel node/slot/port[:subport]
5. (Optional) Reconfigure the interface speed in INTERFACE mode.
speed {8 | 16 | 32 | auto}
6. Apply vfabric configuration on the interface. For more information about vfabric configuration, see Virtual fabric.
vfabric fabric-ID
7. Enable the FC interface in INTERFACE mode.
no shutdown
Configure FC interface
OS10(config)# port-group 1/1/15
OS10(conf-pg-1/1/15)# mode FC 16g-4x
OS10(conf-pg-1/1/15)# exit
OS10(config)# interface fibrechannel 1/1/43:1
OS10(conf-if-fc-1/1/43:1)# speed 32
OS10(conf-if-fc-1/1/43:1)# no shutdown
View FC interface
OS10(config)# interface fibrechannel 1/1/43:1
OS10(conf-if-fc-1/1/43:1)# show configuration
!
interface fibrechannel1/1/43:1
no shutdown
speed 32
vfabric 100
OS10# show interface fibrechannel 1/1/43:1
Fibrechannel 1/1/43:1 is up, FC link is up
Address is 14:18:77:20:8d:fc, Current address is 14:18:77:20:8d:fc
Pluggable media present, QSFP+ type is QSFP+ 4x(16GBASE FC SW)
Wavelength is 850
Receive power reading is 0.0
FC MTU 2188 bytes
LineSpeed 8G
Port type is F, Max BB credit is 1
WWN is 20:78:14:18:77:20:8d:cf
Last clearing of "show interface" counters: 00:02:32
Input statistics:
33 frames, 3508 bytes
0 class 2 good frames, 33 class 3 good frames
0 frame too long, 0 frame truncated, 0 CRC
1 link fail, 0 sync loss
0 primitive seq err, 0 LIP count
0 BB credit 0, 0 BB credit 0 packet drops
Output statistics:
33 frames, 2344 bytes
