Alarm Category Alarm Name Traps Generated? Severity Level
Bias low warning N Minor
Power transmission
(Tx)
Tx high Y Major
Tx high warning N Minor
Tx low Y Major
Tx low warning N Minor
Power reception (Rx) Rx high Y Major
Rx high warning N Minor
Rx low Y Major
Rx low warning N Minor
You can enable or disable the DOM feature, configure traps, and view the DOM status.
Enable DOM and DOM traps
To generate DOM alarms, do the following.
1. Enable DOM.
OS10(config)# dom enable
2. Enable DOM traps.
OS10(config)# snmp-server enable traps dom
You can run the show alarms command in EXEC mode to view any alarms that are generated.
View DOM alarms
OS10# show alarms
Index Severity Name Raise-time Source
----- -------- ------------------- ----------------------- ------
0 major EQM_MEDIA_TEMP_HIGH Tue 06-04-2019 12:32:07 Node.1-Unit.1
View DOM event log message
The following are examples of event logs:
• High temperature warning:
Aug 03 06:35:47 OS10 dn_eqm[9135]: [os10:alarm], %Dell EMC (OS10)
%EQM_MEDIA_TEMP_HIGH: Media high temperature threshold crossed major warning
SET media 1/1/21 high threshold crossed, 82.00:78.00 Aug 03 06:35:47 OS10
dn_eqm[9135]: [os10:alarm], %Dell EMC (OS10) %EQM_MEDIA_VOLTAGE_HIGH: Media high
voltage threshold crossed major warning SET media 1/1/21 high threshold crossed,
6.00:3.63
In this example, the threshold for high temperature is 78.00, but the current temperature is 82.00.
• High reception power warning:
Aug 03 06:35:47 OS10 dn_eqm[9135]: [os10:alarm], %Dell EMC (OS10)
%EQM_MEDIA_RX_POWER_HIGH: Media high rx_power threshold crossed major warning
SET media 1/1/21 high threshold crossed, 7.00:3.30 Aug 03 06:35:47 OS10
dn_eqm[9135]: [os10:alarm], %Dell EMC (OS10) %EQM_MEDIA_BIAS_HIGH: Media high
bias threshold crossed major warning SET media 1/1/21 high threshold crossed,
120.00:105.00
In this example, the threshold for high reception power is 3.30, but the current reception power is 7.00.
View DOM traps
