Users Guide

duplex
Configures Duplex mode on the Management port.
Syntax
duplex {full | half | auto}
Parameters
• full — Set the physical interface to transmit in both directions.
• half — Set the physical interface to transmit in only one direction.
• auto — Set the port to auto-negotiate speed with a connected device.
Defaults Not configured
Command Mode CONFIGURATION
Usage Information You can only use this command on the Management port. The no version of this command removes the duplex
mode configuration from the management port.
Example
OS10(conf-if-ma-1/1/1)# duplex auto
Supported
Releases
10.3.0E or later
enable dom
Enables or disables the DOM feature.
Syntax
dom enable
Parameters None
Default Disabled
Command Mode CONFIGURATION
Usage Information The no version of this command disables digital optical monitoring.
Example
OS10# configure terminal
OS10(config)# dom enable
OS10# configure terminal
OS10(config)# no dom enable
Supported
Releases
10.4.3.0 or later
enable dom traps
Enables DOM traps if the specified parameter crosses the defined threshold three times.
Syntax
snmp-server enable traps dom {temperature | voltage | rx-power | tx-power |
bias}
Parameters temperature | voltage | rx-power | tx-power | bias — Enter the keyword to enable DOM
traps for the specified category.
Default Not configured
Command Mode CONFIGURATION
Usage Information The no version of this command disables the DOM traps.
256 Interfaces
