OS10(conf-if-eth1/1/50)# negotiation on
OS10(conf-if-eth1/1/50)# show configuration
!
interface ethernet1/1/50
no shutdown
switchport access vlan 1
negotiation on
flowcontrol receive on
OS10(conf-if-eth1/1/50)# no negotiation
OS10(conf-if-eth1/1/50)# show configuration
!
interface ethernet1/1/50
no shutdown
switchport access vlan 1
flowcontrol receive on
OS10(conf-if-eth1/1/50)# do show interface ethernet 1/1/50
Ethernet 1/1/50 is up, line protocol is up
Hardware is Eth, address is e4:f0:04:3e:2d:86
Current address is e4:f0:04:3e:2d:86
Pluggable media present, QSFP28 type is QSFP28 100GBASE-CR4-2.0M
Wavelength is 64
Receive power reading is not available
Interface index is 112
Internet address is not set
Mode of IPv4 Address Assignment: not set
Interface IPv6 oper status: Disabled
MTU 1532 bytes, IP MTU 1500 bytes
LineSpeed 100G, Auto-Negotiation on
Supported
Releases
10.2.0E or later
port mode Eth
Configures a Z9264F-ON QSFP28 port group to operate in Ethernet mode, with the specified speed on activated interfaces.
Syntax
port node/slot/port mode Eth port-mode
Parameters
• node/slot/port — Enter the interface type details.
• mode Eth — Configure a port group in Ethernet mode and set the speed to:
• 100g-1x — Reset a port to 100GE mode.
• 50g-2x — Split a port into two 50GE interfaces.
•
40g-1x — Set a port to 40GE mode for use with a QSFP+ 40GE transceiver.
• 25g-4x — Split a port into four 25GE interfaces.
• 10g-4x — Split a port into four 10GE interfaces.
Default 100g-1x
Command mode PORT-GROUP
Usage information To view the currently active ports and subports, use the show port-group command. The no version of the
command resets port-group interfaces to the default Ethernet port mode/speed.
Example
OS10(config)# port-group 1/1/2
OS10(conf-pg-1/1/2)# profile restricted
OS10(conf-pg-1/1/2)# port 1/1/3 mode Eth 25g-4x
OS10(conf-pg-1/1/2)# exit
OS10(config)# interface ethernet 1/1/3:2
OS10(conf-if-eth1/1/3:2)#
Supported
releases
10.4.3.0 or later
