Users Guide

Members in this channel:
ARP type: ARPA, ARP Timeout: 60
OS10# show interface port-channel summary
LAG Mode Status Uptime Ports
22 L2 up 20:38:08 Eth 1/1/10 (Up)
Eth 1/1/11 (Down)
Eth 1/1/12 (Inact)
23 L2 up 20:34:32 Eth 1/1/20 (Up)
Eth 1/1/21 (Up)
Eth 1/1/22 (Up)
Example (VLAN)
OS10# show interface vlan 20
Vlan 20 is up, line protocol is down
vlan name: vlanname20
Address is 0c:9b:1d:68:89:6a, Current address is 0c:9b:1d:68:89:6a
Interface index is 60
Internet address is not set
Mode of IPv4 Address Assignment: not set
Interface IPv6 oper status: Enabled
MTU 1532 bytes, IP MTU 1500 bytes
LineSpeed 0
ARP type: ARPA, ARP Timeout: 60
Last clearing of "show interface" counters: 00:05:14
Queuing strategy: fifo
Input statistics:
0 packets, 0 octets
Output statistics:
0 packets, 0 octets
Time since last interface status change: 00:05:15
Supported
Releases
10.2.0E or later
show interface transceiver “Tunable wavelength”
Display the configured wavelength value of the optical interface.
Syntax
show interface phy-eth interface transceiver | grep “Tunable wavelength”
Parameters interface — Specify the interface corresponding to which you want to view the optical wavelength details.
Defaults None.
Command Mode EXEC PRIVILEGE
Usage Information None.
Example
OS10# show interface phy-eth 1/1/14 transceiver | grep "Tunable wavelength"
SFP1/1/14 Tunable wavelength= 1530.000nm
Supported
Releases
10.4.2E or later
show inventory media
Displays installed media in switch ports.
Syntax
show inventory media
Parameters None
Command Mode EXEC
268 Interfaces
