Users Guide

Example
OS10(config)# fc zone hba1
OS10(config-fc-zone-hba1)# member wwn 10:00:00:90:fa:b8:22:19
OS10(config-fc-zone-hba1)# member wwn 21:00:00:24:ff:7b:f5:c8
Supported
Releases
10.3.1E or later
fc zoneset
Creates an FC zoneset and adds the existing FC zones to the zoneset.
Syntax
fc zoneset zoneset-name
Parameters zoneset-name — Enter a name for the FC zoneset. The name must start with a letter and may contain these
characters: A-Z, a-z, 0-9, $, _, -, ^
Defaults Not configured
Command Mode CONFIGURATION
Usage Information
The no version of this command removes the FC zoneset.
Supported on the MX9116n switch in Full Switch mode starting in release 10.4.1.0. Also supported in SmartFabric
mode starting in release 10.5.0.1.
Example
OS10(config)# fc zoneset set
OS10(conf-fc-zoneset-set)# member hba1
Supported
Releases
10.3.1E or later
feature fc
Enables the F_Port globally.
Syntax
feature fc domain-id domain-id
Parameters domain-id — Enter the domain ID of the F_Port, from 1 to 239.
Defaults Disabled
Command Mode CONFIGURATION
Usage Information
The no version of this command disables the F_Port. You can disable the F_Port only when vfabric and zoning
configurations are not available. Before disabling the F_Port, remove the vfabric and zoning configurations. You
can enable only one of the following at a time: F_Port, NPG, or FSB.
Example
OS10(config)# feature fc domain-id 100
Supported
Releases
10.3.1E or later
member (alias)
Add members to existing FC aliases. Identify a member by an FC alias, a world wide name (WWN), or an FC ID.
Syntax
member {wwn wwn-ID | fc-id fc-id}
Parameters
• wwn-ID — Enter the WWN name.
• fc-id — Enter the FC ID name.
Defaults Not configured
Fibre Channel 335
