TLV Subtype Description
Originator 1 Indicates the OS10 string that is used as
originator. The string enables the OS10
switches to identify LLDP PDUs.
Role 2 Following are the applicable roles:
1. LEAF
2. SPINE
3. UNKNOWN
IP address 3 Indicates the IPv6 address of the originator.
Virtual IP address of the fabric 4 Virtual IP address of the master node. The
Isilon nodes can also use this IPv6 address
when needed.
MAC address of the physical interface 5 MAC address used by the OS10 switches
for ND.
Table 37. Service tag TLV (Type – 127, OUI – 0xF8-0xB1-0x56)
TLV Subtype Description
Service tag 21 Indicates the service tag that is associated
with the device.
Table 38. Solution ID TLVs (Type – 127, OUI – 0xF8-0xB1-0x56)
TLV Subtype Description
Product base 22 Indicates the product base.
Product serial number 23 Indicates the product serial number.
Product part number 24 Indicates the product part number.
Media endpoint discovery
LLDP-MED provides organizationally specific TLVs to allow endpoint devices and network-connectivity devices to advertise their
characteristics and configuration information.
LLDP-MED devices at the IEEE 802 LAN network edge participate in IP communication service using the LLDP-MED framework, such as
IP phones and conference bridges. LLDP-MED network connectivity devices provide access to the IEEE 802-based LAN infrastructure for
LLDP-MED endpoint devices, such as IP phones. An OS10 device acts as an LLDP-MED network connectivity device.
LLDP-MED provides network connectivity devices to:
• Manage inventory.
• Manage power over Ethernet (PoE).
• Identify physical location.
• Identify network policy.
NOTE:
Only the Rx function is supported for managing PoE and identifying the physical location. LLDP-MED is designed
for but not limited to VoIP endpoints.
Network connectivity device
OS10 acts as an LLDP-MED network-connectivity device (Type 4). Network connectivity devices transmit an LLDP-MED capability TLV
to endpoint devices and stores information that endpoint devices advertise.
127/1 — LLDP-
MED capabilities
• If the transmitting device supports LLDP-MED
• What LLDP-MED TLVs are supported
• LLDP device class
