NOTE: In SmartFabric Services mode, creation of VLAN is disabled.
Example
OS10(config)# interface vlan 10
OS10(conf-if-vl-10)#
Supported
Releases
10.2.0E or later
show vlan
Displays VLAN configurations.
Syntax
show vlan vlan-id
Parameters vlan-id — (Optional) Enter a VLAN ID number, from 1 to 4093.
Default Not configured
Command Mode EXEC
Usage Information Use this command to view VLAN configuration information for a specific VLAN ID.
Example
OS10(config)# do show vlan
Codes: * - Default VLAN, M - Management VLAN, R - Remote Port Mirroring VLANs
Q: A - Access (Untagged), T - Tagged
NUM Status Description Q Ports
* 1 Active A Eth1/1/15
A Po100
2101 Active T Eth1/1/1,1/1/3
T Po100
2102 Active T Eth1/1/1,1/1/3
Supported
Releases
10.2.0E or later
Port monitoring
Port monitoring monitors ingress or egress traffic of one port to another for analysis. A monitoring port (MG) or destination port, is the
port where the monitored traffic is sent for analysis. A monitored port (MD) or source port is the source interface that is monitored for
traffic analysis.
NOTE:
This feature is not supported on the Z9332F-ON platform.
The different types of port monitoring are:
• Local port monitoring — Port monitoring is done in the same switch. The switch forwards a copy of incoming and outgoing traffic
from one port to another port for further analysis.
• Remote port monitoring (RPM) — Port monitoring is done on traffic running across a remote device in the same network. The L2
network carries the monitored traffic.
• Encapsulated remote port monitoring (ERPM) — Port monitoring is done on the L3 network. The traffic from the source port is
encapsulated and forwards to the destination port in another switch.
Local port monitoring
For local port monitoring, the monitored source ports and monitoring destination ports are on the same device.
Configure local monitoring session
1. Verify that the intended monitoring port has no configuration other than no shutdown and no switchport.
show running-configuration
