Users Guide

3. Configure source and destination IP addresses, and protocol type in MONITOR-SESSION mode.
source-ip source ip-address destination-ip destination ip-address [gre-protocol protocol-
value]
4. Configure TTL and DSCP values in MONITOR-SESSION mode.
ip {ttl ttl-number | dscp dscp-number}
5. Enable the monitoring interface in MONITOR-SESSION mode.
no shut
Create monitoring session
OS10(config)# monitor session 10 type erpm-source
OS10(conf-mon-erpm-source-10)#
Configure source port, source and destination IP addresses, and protocol type
OS10(conf-mon-erpm-source-10)# source interface ethernet 1/1/2
OS10(conf-mon-erpm-source-10)# source-ip 1.1.1.1 destination-ip 3.3.3.3 gre-protocol 35006
OS10(conf-mon-erpm-source-10)# ip ttl 16
OS10(conf-mon-erpm-source-10)# ip dscp 63
OS10(conf-mon-erpm-source-10)# no shut
View configured ERPM session
OS10(conf-mon-erpm-source-6)# do show monitor session all
S.Id Source Destination Dir Mode Source IP Dest IP DSCP TTL Gre-Protocol State
Reason
----------------------------------------------------------------------------------------------
----
6 ethernet1/1/2 remote-ip both port 1.1.1.1 3.3.3.3 63 16 35006 true
Is UP
View running configuration of monitor session
OS10# show running-configuration monitor
!
monitor session 10 type erpm-source
source-ip 1.1.1.1 destination-ip 3.3.3.3
source interface ethernet1/1/2
no shut
Flow-based monitoring
Flow-based monitoring conserves bandwidth by inspecting only specified traffic instead of all interface traffic. Using flow-based
monitoring, you can monitor only traffic received by the source port that matches criteria in ingress access-lists (ACLs). IPv4 ACLs, IPv6
ACLs, and MAC ACLs support flow-based monitoring.
1. Enable flow-based monitoring for a monitoring session in MONITOR-SESSION mode.
flow-based enable
2. Return to CONFIGURATION mode.
exit
3. Create an access list in CONFIGURATION mode.
ip access-list access-list-name
