Users Guide

Supported
Releases
10.4.0E(R1) or later
ip tftp vrf
Configures a TFTP client for the management or non-default VRF instance.
Syntax
ip tftp vrf {management | vrf vrf-name}
Parameters
• management — Enter the keyword to configure a TFTP client for the management VRF instance.
• vrf vrf-name — Enter the keyword then the name of the VRF to configure a TFTP client for that non-
default VRF instance.
Default Not configured
Command Mode CONFIGURATION
Usage Information The no version of this command removes the management VRF instance configuration from the TFTP client.
Example
OS10(config)# ip tftp vrf management
OS10(config)# ip tftp vrf vrf-blue
Supported
Releases
10.4.0E(R1) or later
ip vrf management
Configures the management VRF instance.
Syntax
ip vrf management
Parameters None
Default Not configured
Command Mode CONFIGURATION
Usage Information Enter the ip vrf management command only in non-transaction-based configuration mode. Do not use
transaction-based mode. The no version of this command removes the management VRF instance configuration.
Example
OS10(config)# ip vrf management
OS10(conf-vrf)#
Supported
Releases
10.4.0E(R1) or later
show hosts vrf
Displays the host table in the management or non-default VRF instance.
Syntax
show hosts vrf {management | vrf-name}
Parameters
• management—Enter the keyword management to display the host table in the management VRF instance.
• vrf-name—Enter the name of the non-default VRF instance to display the host table in that VRF instance.
Default Not configured
Command Mode EXEC
Usage Information None
Example
OS10# show hosts vrf management
Default Domain Name : dell.com
Domain List : abc.com xyz.net
Name Servers : 10.16.126.1
=================================================
