6. Add a remote AS in ROUTER-TEMPLATE mode (1 to 65535 for 2 bytes, 1 to 4294967295 for 4 bytes).
remote-as as-number
Allow external routes from neighbor
OS10(config)# router bgp 10
OS10(conf-router-bgp-10)# neighbor 32.1.1.2
OS10(conf-router-neighbor)# local-as 50
OS10(conf-router-neighbor)# exit
OS10(conf-router-bgp-10)# template bgppg1
OS10(conf-router-template)# fall-over
OS10(conf-router-template)# local-as 400
OS10(conf-router-template)# remote-as 102
Local AS number disabled
OS10(config)# router bgp 102
OS10(conf-router-bgp-102)# neighbor 32.1.1.2
OS10(conf-router-neighbor)# no local-as 100
AS number limit
Sets the number of times an AS number occurs in an AS path. The allow-as parameter permits a BGP speaker to allow the AS number
for a configured number of times in the updates received from the peer.
The AS-PATH loop is detected if the local AS number is present more than the number of times in the command.
1. Enter the neighbor IP address to use the AS path in ROUTER-BGP mode.
neighbor ip address
2. Enter Address Family mode in ROUTER-NEIGHBOR mode.
address-family {{ipv4 | ipv6} unicast | l2vpn evpn}
3. Allow the neighbor IP address to use the AS path the specified number of times in ROUTER-BGP-NEIGHBOR-AF mode (1 to 10).
allowas-in number
Configure AS number appearance
OS10(config)# router bgp 10
OS10(conf-router-bgp-10)# neighbor 1.1.1.2
OS10(conf-router-neighbor)# address-family ipv4 unicast
OS10(conf-router-bgp-neighbor-af)# allowas-in 5
View AS numbers in AS paths
OS10# show running-configuration bgp
!
router bgp 101
no fast-external-fallover
!
address-family ipv4 unicast
dampening
!
neighbor 17.1.1.2
remote-as 102
no shutdown
!
address-family ipv4 unicast
allowas-in 4
Show IP BGP
OS10(config)# router bgp 100
OS10(config-router-bgp-100)# neighbor 172:16:1::2
