• password-string—Enter a password for authentication. A maximum of 128 characters.
Default Disabled
Command Mode
ROUTER-NEIGHBOR
ROUTER-TEMPLATE
Usage Information You can enter the password either as plain text or in encrypted format. The password that is provided in
ROUTER-NEIGHBOR mode takes preference over the password in ROUTER-TEMPLATE mode. The no version
of this command disables authentication.
Example
OS10(conf-router-neighbor)# password abcdell
OS10(conf-router-neighbor)# password 9
f785498c228f365898c0efdc2f476b4b27c47d972c3cd8cd9b91f518c14ee42d
Supported
Releases
10.3.0E or later
redistribute
Redistributes connected, static, and OSPF routes in BGP.
Syntax
redistribute {connected [route-map map name] | ospf process-id | static [route-
map map name ]}
Parameters
• connected — Enter to redistribute routes from physically connected interfaces.
• route-map map name — (Optional) Enter the name of a configured route-map.
• ospf process-id — Enter a number for the OSPF process (1 to 65535).
• static — Enter to redistribute manually configured routes.
Default Disabled
Command Mode ROUTER-BGPv4-AF or ROUTER-BGPv6-AF
Usage Information Static routes are treated as incomplete routes. When you use the redistribute ospf process-id
command without other parameters, the system redistributes all OSPF internal routes, external type 1 routes, and
external type 2 routes. The no version of this command resets the value to the default.
Example
(Connected)
OS10(conf-router-bgp-102)# address-family ipv4 unicast
OS10(conf-router-bgpv4-af)# redistribute connected route-map mapbgp1
Example (Static
— IPv4)
OS10(conf-router-bgp-102)# address-family ipv4 unicast
OS10(conf-router-bgpv4-af)# redistribute static route-map mapbgp2
Example (Static
— IPv6)
OS10(conf-router-bgp-102)# address-family ipv6 unicast
OS10(conf-router-bgpv6-af)# redistribute static
Example (OSPF —
IPv4)
OS10(conf-router-bgp-102)# address-family ipv4 unicast
OS10(conf-router-bgpv4-af)# redistribute ospf 1
Example (OSPF —
IPv6)
OS10(conf-router-bgp-102)# address-family ipv6 unicast
OS10(conf-router-bgpv6-af)# redistribute ospf 1
Supported
Releases
10.2.0E or later
