LineSpeed 40G, Auto-Negotiation on
Flowcontrol rx off tx off
ARP type: ARPA, ARP Timeout: 60
Last clearing of "show interface" counters: 3 weeks 1 day 23:12:50
Queuing strategy: fifo
Input statistics:
0 packets, 0 octets
0 64-byte pkts, 0 over 64-byte pkts, 0 over 127-byte pkts
0 over 255-byte pkts, 0 over 511-byte pkts, 0 over 1023-byte pkts
0 Multicasts, 0 Broadcasts, 0 Unicasts
0 runts, 0 giants, 0 throttles
0 CRC, 0 overrun, 0 discarded
Output statistics:
0 packets, 0 octets
0 64-byte pkts, 0 over 64-byte pkts, 0 over 127-byte pkts
0 over 255-byte pkts, 0 over 511-byte pkts, 0 over 1023-byte pkts
0 Multicasts, 0 Broadcasts, 0 Unicasts
0 throttles, 0 discarded, 0 Collisions, 0 wreddrops
Rate Info(interval 299 seconds):
Input 0 Mbits/sec, 0 packets/sec, 0% of line rate
Output 0 Mbits/sec, 0 packets/sec, 0% of line rate
Time since last interface status change: 3 weeks 1 day 20:54:37
Configure static routing
You can configure a manual or static route for open shortest path first (OSPF).
• Configure a static route in CONFIGURATION mode.
ip route ip-prefix/mask {next-hop | interface interface [route-preference]}
• ip-prefix—IPv4 address in dotted decimal in A.B.C.D format.
• mask—Mask in slash prefix-length format (/X).
• next-hop—Next-hop IP address in dotted decimal in A.B.C.D format.
• interface—Interface type with the node/slot/portinformation
• route-preference—(Optional) Route-preference range, from 1 to 255.
Configure static routes
OS10(config)# ip route 200.200.200.0/24 10.1.1.2
View configured static routes
OS10# show ip route static
Codes: C - connected
S - static
B - BGP, IN - internal BGP, EX - external BGP
O - OSPF,IA - OSPF inter area, N1 - OSPF NSSA external type 1,
N2 - OSPF NSSA external type 2, E1 - OSPF external type 1,
E2 - OSPF external type 2, > - non-active route
Gateway of last resort is not set
Destination Gateway Dist/Metric Last Change
------------------------------------------------------------------
S 200.200.200.0/24 via 10.1.1.2 ethernet1/1/1 0/0 00:00:03
OS10 installs a static route if the next hop is on a directly connected subnet. A next-hop that is not on the directly connected subnet
which recursively resolves to a next-hop on the interface's configured subnet also automatically configures. For example, if interface
ethernet 1/1/5 has IP address on subnet 100.0.0.0/8, and if 10.1.1.0/24 recursively resolves to 100.1.1.1, the system installs the static
route:
• When the interface goes down, OS10 withdraws the route.
• When the interface comes up, OS10 reinstalls the route.
• When the recursive resolution is broken, OS10 withdraws the route.
• When the recursive resolution is satisfied, OS10 reinstalls the route.
