Users Guide

Example
OS10# configure terminal
OS10(config)#
Supported
Releases
10.2.0E or later
copy
Copies the current running configuration to the startup configuration and transfers files between an OS10 switch and a remote device.
Syntax
copy running-configuration [startup-configuration | config://filepath |
coredump://filepath | ftp://filepath | home://filepath | scp://filepath | sftp://
filepath | severity-profile profile-name | supportbundle://filepath | tftp://
filepath | usb://filepath]
Parameters
• running-configuration startup-configuration — (Optional) Copy the current running
configuration file to the startup configuration file.
• config://filepath — (Optional) Copy from the configuration directory.
• coredump://filepath — (Optional) Copy from the coredump directory.
• ftp://userid:passwd@hostip/filepath — (Optional) Copy from a remote FTP server.
• home://username/filepath — (Optional) Copy from the home directory.
• scp://userid:passwd@hostip/filepath — (Optional) Copy from a remote SCP server.
• sftp://userid:passwd@hostip/filepath — (Optional) Copy from a remote SFTP server.
• supportbundle://filepath — (Optional) Copy from the support-bundle directory.
• severity-profile://filepath — (Optional) Copy from the severity-profile directory.
• tftp://hostip/filepath — (Optional) Copy from a remote TFTP server.
• usb:filepath — (Optional) Copy from a USB file system.
Default Not configured
Command Mode EXEC
Usage Information Use this command to save the running configuration to the startup configuration, transfer coredump files to a remote
location, backup the startup configuration, retrieve a previously backed-up configuration, replace the startup
configuration file, or transfer support bundles.
CAUTION: Dell EMC Networking recommends that you do not use a copy command to download an
OS10 image to the switch. The downloaded image occupies a large amount of disk space. Use the
image download command to download an OS10 image.
When using the scp and sftp options, always enter an absolute file path instead of a path relative to the home
directory of the user account; for example:
copy config://startup.xml scp://dellos10:password@10.1.1.1/home/dellos10/
backup.xml
Use the copy command with the severity-profile option to download or upload severity profiles from a
remote location. When you copy a severity profile from a remote location to an OS10 switch, ensure that the name of
the severity profile is different than that of the default profile (default.xml) or the currently active severity profile.
Example
OS10# dir coredump
Directory contents for folder: coredump
Date (modified) Size (bytes) Name
--------------------- ------------ ------------------
2017-02-15T19:05:41Z 12402278 core.netconfd-
pro.2017-02-15_19-05-09.gz
OS10# copy coredump://core.netconfd-pro.2017-02-15_19-05-09.gz scp://
os10user:os10passwd@10.11.222.1/home/os10/core.netconfd-pro.2017-02
-15_19-05-09.gz
60 CLI Basics
