ip ospf retransmit-interval
Sets the retransmission time between lost LSAs for adjacencies belonging to the interface.
Syntax
ip ospf retransmit-interval seconds
Parameters seconds — Enter a value in seconds as the interval between retransmission, from 1 to 3600.
Default 5 seconds
Command Mode INTERFACE
Usage Information Set the time interval to a number large enough to avoid unnecessary retransmission. The no version of this
command resets the value to the default.
Example
OS10(conf-if-eth1/1/6)# ip ospf retransmit-interval 20
Supported
Releases
10.2.0E or later
ip ospf transmit-delay
Sets the estimated time required to send a link state update packet on the interface.
Syntax
ip ospf transmit-delay seconds
Parameters seconds — Set the time in seconds required to send a link-state update, from 1 to 3600.
Default 1 second
Command Mode INTERFACE
Usage Information When you set the ip ospf transmit-delay value, take into account the transmission and propagation
delays for the interface. The no version of this command resets the value to the default.
Example
OS10(conf-if-eth1/1/4)# ip ospf transmit-delay 5
Supported
Releases
10.2.0E or later
log-adjacency-changes
Enables logging of syslog messages regarding changes in the OSPF adjacency state.
Syntax
log-adjacency-changes
Parameters None
Default Disabled
Command Mode ROUTER-OSPF
Usage Information The no version of this command resets the value to the default.
Example
OS10(config)# router ospf 10
OS10(conf-router-ospf-10)# log-adjacency-changes
Supported
Releases
10.2.0E or later
max-metric router-lsa
Configures OSPF to advertise a maximum metric on a router so that it is not desired as an intermediate hop from other routers.
Syntax
max-metric router-lsa
Parameters None
Default Not configured
Command Mode ROUTER-OSPF
