Users Guide

Usage Information Routers in the network do not prefer other routers as the next intermediate hop after they calculate the shortest
path. The no version of this command disables the maximum metric advertisement configuration.
Example
OS10(conf-router-ospf-10)# max-metric router-lsa
Supported
Releases
10.2.0E or later
maximum-paths
Enables forwarding of packets over multiple paths.
Syntax
maximum—paths number
Parameters number —Enter the number of paths for OSPF, from 1 to 128.
Default 64
Command Mode ROUTER-OSPF
Usage Information The no version of this command resets the value to the default.
Example
OS10(config)# router ospf 10
OS10(conf-router-ospf-10)# maximum-paths 1
Supported
Releases
10.2.0E or later
redistribute
Redistributes information from another routing protocol or routing instance to the OSPFv2 process.
Syntax
redistribute {bgp as-number| connected | static} [route-map map-name]
Parameters
• as-number — Enter an autonomous number to redistribute BGP routing information throughout the OSPF
instance, from 1 to 4294967295.
• connected — Enter the information from the connected active routes on interfaces to redistribute.
• static — Enter the information from static routes on interfaces to redistribute.
• route-map name — Enter the name of a configured route-map.
Defaults Not configured
Command Mode ROUTER-OSPF
Usage Information When an OSPF redistributes, the process does not completely remove from the BGP configuration. The no
version of this command disables the redistribute configuration.
Example
OS10(config)# router ospf 10
OS10(conf-router-ospf-10)# redistribute bgp 4 route-map dell1
Example
(Connected)
OS10(config)# router ospf 10
OS10(conf-router-ospf-10)# redistribute connected route-map dell2
Supported
Releases
10.2.0E or later
router-id
Configures a fixed router ID for the OSPF process.
Syntax
router-id ip-address
Parameters ip-address — Enter the IP address of the router as the router ID.
Default Not configured
Layer 3 629
