Users Guide

exit
Returns to the next higher command mode.
Syntax
exit
Parameters None
Default Not configured
Command Mode All
Usage Information None
Example
OS10(conf-if-eth1/1/1)# exit
OS10(config)#
Supported
Releases
10.2.0E or later
hostname
Sets the system host name.
Syntax
hostname name
Parameters name — Enter the host name of the switch, a maximum of 64 characters.
Default OS10
Command Mode CONFIGURATION
Usage Information
The host name is used in the OS10 command-line prompt.
The MX7000 series switch, not the Dell EMC SmartFabric OS10, automatically sets the default hostname using a
module-slot format. To calculate the hostname, the switch takes into account the module that is currently
plugged into the MX7000 chassis and the slot in the chassis where the module is inserted. The module can be
either MX9116n or MX5108n.
NOTE: To make the switch automatically set the default hostname using the module-slot format,
before upgrading to version 10.5.0, remove the user-defined hostname or set the default
hostname using the no hostname command.
Supported on the MX9116n and MX5108n switches in Full-Switch mode starting in release 10.4.0(R3S). Also
supported in SmartFabric Services mode starting in 10.5.0.
The no version of this command resets the host name to OS10.
Example
OS10(conf)# hostname R1
R1(conf)#
Supported
Releases
10.3.0E or later
license
Installs a license file from a local or remote location.
Syntax
license install [ftp: | http: | localfs: | scp: | sftp: | tftp: | usb:]
filepath
Parameters
• ftp: — (Optional) Install from the remote file system (ftp://userid:passwd@hostip/filepath).
• http[s]: — (Optional) Install from the remote file system (http://hostip/filepath).
• http[s]: — (Optional) Request from remote server (http://hostip).
64 CLI Basics
