Users Guide

Supported
Releases
10.3.0E or later
ipv6 ospf authentication
Configures OSPFv3 authentication on an IPv6 interface.
Syntax
ipv6 ospf authentication {null | ipsec spi number {MD5 | SHA1} key}
Parameters
• null — Prevents area authentication from being inherited on the interface.
• ipsec spi number — Enter a unique security policy index number, from 256 to 4294967295.
• md5 — Enable MD5 authentication.
• sha1 — Enable SHA1 authentication.
• key — Enter the text string used by the authentication type.
Default IPv6 OSPF authentication is not configured on an interface.
Command Mode INTERFACE
Usage Information
• Before you enable IPsec authentication on an OSPFv3 interface, you must enable IPv6 unicast routing globally,
configure an IPv6 address and enable OSPFv3 on the interface, and assign it to an area.
• The SPI value must be unique to one IPsec authentication or encryption security policy on the router. You
cannot configure the same SPI value on another interface even if it uses the same authentication or
encryption algorithm.
• You cannot use an IPsec MD5 or SHA1 authentication type and the null setting at same time on an
interface. These settings are mutually exclusive.
• All neighboring OSPFv3 routers must share the key to exchange information. Only a non-encrypted key is
supported. For MD5 authentication, the non-encrypted key must be 32 plain hex digits. For SHA1
authentication, the non-encrypted key must be 40 hex digits. An encrypted key is not supported.
Example
OS10(config)# interface ethernet 1/1/6
OS10(conf-if-eth1/1/6)# ipv6 ospf authentication ipsec spi 400 md5
12345678123456781234567812345678
Supported
Releases
10.4.0E(R1) or later
ipv6 ospf cost
Changes the cost associated with the OSPFv3 traffic on an interface
Syntax
ipv6 ospf cost cost
Parameters cost — Enter a value as the OSPFv3 cost for the interface, from 1 to 65335.
Default Based on bandwidth reference
Command Mode INTERFACE
Usage Information If not configured, the interface cost is based on the auto-cost command. This command configures OSPFv3
over multiple vendors to ensure that all routers use the same cost value. The no version of this command
removes the IPv6 OSPF cost configuration.
Example
OS10(config)# interface vlan 10
OS10(conf-if-vl-10)# ipv6 ospf cost 10
Supported
Releases
10.3.0E or later
ipv6 ospf dead-interval
Sets the time interval since the last hello-packet was received from a router. After the interval elapses, the neighboring routers declare the
router dead.
Syntax
ipv6 ospf dead-interval seconds
Layer 3 655
