Users Guide

Default 10 seconds
Command Mode INTERFACE
Usage Information All routers in a network must have the same hello time interval between the hello packets. The no version of the
this command resets the value to the default.
Example
OS10(config)# interface vlan 10
OS10(conf-if-vl-10)# ipv6 ospf hello-interval 30
Supported
Releases
10.3.0E or later
ipv6 ospf network
Sets the network type for the interface.
Syntax
ipv6 ospf network {point-to-point | broadcast}
Parameters
• point-to-point — Sets the interface as part of a point-to-point network.
• broadcast — Sets the interface as part of a broadcast network.
Default Broadcast
Command Mode INTERFACE
Usage Information The no version of this command resets the value to the default.
Example
OS10(config)# interface ethernet 1/1/1
OS10(conf-if-eth1/1/1)# ipv6 ospf network broadcast
Supported
Releases
10.3.0E or later
ipv6 ospf passive
Configures an interface as a passive interface and suppresses both receiving and sending routing updates to the passive interface.
Syntax
ipv6 ospf passive
Parameters None
Default Not configured
Command Mode INTERFACE
Usage Information You must configure the interface before setting the interface to passive mode. The no version of the this
command disables Passive interface configuration.
NOTE: As loopback interfaces are implicitly passive, the configuration to suppress sending and
receiving of OSPF routing updates does not take effect on the loopback interfaces. However,
network information corresponding to these loopback interfaces is still announced in OSPF LSAs
that are sent through other interfaces configured for OSPF.
Example
OS10(config)# interface ethernet 1/1/6
OS10(conf-if-eth1/1/6)# ipv6 ospf passive
Supported
Releases
10.3.0E or later
ipv6 ospf priority
Sets the priority of the interface to determine the DR for the OSPFv3 network.
Syntax
ipv6 ospf priority number
Parameters number — Enter a router priority number, from 0 to 255.
Layer 3 657
