Users Guide

• State—Displays the OSPF state of the neighbor.
• Dead Time—Displays the expected time until the system declares the neighbor dead.
• Interface ID—Displays the neighbor interface ID
• Interface—Displays the interface type, node/slot/port or number information.
Example
OS10(conf-if-eth1/1/1)# show ipv6 ospf neighbor
Neighbor ID Pri State Dead Time Interface ID Interface
-------------------------------------------------------------------
2.2.2.2 1 Full/DR 00:00:30 5 ethernet1/1/1
Supported
Releases
10.3.0E or later
show ipv6 ospf statistics
Displays OSPFv3 traffic statistics.
Syntax
show ipv6 ospf [instance-number] statistics [interface interface]
Parameters
• instance-number — (Optional) Enter an OSPFv3 instance number, from 1 to 65535.
• interface interface — (Optional) Enter the interface information:
• ethernet node/slot/port[:subport] — Enter an Ethernet port interface.
• port-channel number — Enter the port-channel interface number, from 1 to 128.
•
vlan vlan-id — Enter the VLAN ID number, from 1 to 4093.
Default Not configured
Command Mode EXEC
Usage Information This command displays OSPFv3 traffic statistics for a specified instance or interface, or for all OSPFv3 instances
and interfaces.
Example
OS10# show ipv6 ospf interface ethernet 1/1/1
Interface ethernet1/1/1
Receive Statistics
rx-invalid 0 rx-invalid-bytes 0
rx-hello 0 rx-hello-bytes 0
rx-db-des 0 rx-db-des-bytes 0
rx-ls-req 0 rx-ls-req-bytes 0
rx-ls-upd 0 rx-ls-upd-bytes 0
rx-ls-ack 0 rx-ls-ack-bytes 0
Transmit Statistics
tx-hello 1054 tx-hello-bytes 37944
tx-db-des 0 tx-db-des-bytes 0
tx-ls-req 0 tx-ls-req-bytes 0
tx-ls-upd 0 tx-ls-upd-bytes 0
tx-ls-ack 0 tx-ls-ack-bytes 0
Error packets (Receive statistics)
bad-src 0 dupe-id 0 hello-err 0
mtu-mismatch 0 nbr-ignored 0
resource-err 0 bad-lsa-len 0 lsa-bad-type 0
lsa-bad-len 0 lsa-bad-cksum 0
hello-tmr-mismatch 0 dead-ivl-mismatch 0
options-mismatch 0 nbr-admin-down 0 own-hello-drop 0
self-orig 0 wrong-length 0
version-mismatch 0 area-mismatch 0
Supported
Releases
10.4.0E(R1) or later
timers spf (OSPFv3)
Enables shortest path first (SPF) throttling to delay an SPF calculation when a topology change occurs.
Syntax
timers spf [start-time [hold-time [max-wait]]]
662 Layer 3
