Example
OS10# configure terminal
OS10(config)# ip pim ssm-range ssm
Supported
Releases
10.4.3.0 or later
show ip pim bsr-router
Displays information about the bootstrap router.
Syntax
show ip pim [vrf vrf-name] bsr-router
Parameters vrf vrf-name—Enter the keyword vrf, then the name of the VRF.
Default None
Command Mode EXEC
Usage Information None
Example
OS10# show ip pim bsr-router
PIMv2 Bootstrap information
BSR address: 101.0.0.1
BSR Priority: 199, Hash mask length: 31
Expires: 00:00:24
This system is a candidate BSR
Candidate BSR address: 104.0.0.1, priority: 99, hash mask length: 31
Next Cand_RP_advertisement in 00:00:15
RP: 104.0.0.1(loopback101)
Supported
Releases
10.5.0 or later
show ip pim interface
Displays information about IP PIM-enabled interfaces.
Syntax
show ip pim [vrf vrf-name] interface
Parameters vrf vrf-name—Enter the keyword vrf, then the name of the VRF.
Default None
Command Mode EXEC
Usage Information The show ip pim interface command displays the following:
• Address—IP addresses of the IP PIM-enabled interfaces
• Interface—Interface type with slot/port information or VLAN/Port Channel ID
• Version/Mode—PIM version number and mode; v2 for PIM version 2 and S for PIM sparse mode
• Nbr Count—Active neighbor count on the PIM-enabled interface
• Query interval—Query interval for router query messages on that interface
• DR priority—Designated router priority value configured on that interface
• DR—IP address of the DR for that interface
Example
OS10# show ip pim interface
Address Interface Ver/Mode Nbr Count Query Intvl DR Prio DR
----------------------------------------------------------------------
2.2.2.2 vlan103 v2/S 1 30 1 2.2.2.2
3.3.3.2 vlan105 v2/S 1 30 1 3.3.3.2
122.1.1.2 vlan121 v2/S 0 30 1 122.1.1.2
Supported
Releases
10.4.3.0 or later
