Example
OS10(config)# evpn
OS10(config-evpn)# auto-evi
Supported
releases
10.4.2.0 or later
evi
Creates an EVPN instance (EVI) in EVPN mode.
Syntax
evi id
Parameters
id
Enter the EVPN instance ID, from 1 to 65535.
Default Not configured
Command mode EVPN
Usage information If an MP-BGP network uses 4-byte autonomous systems or to specify the RD and RT values, manually configure
EVPN instances and associate each EVI with the overlay VXLAN virtual network. The EVI activates only when you
configure the VXLAN network ID (VNI), RD, RT, and virtual network.
Example
OS10(config)# evpn
OS10(config-evpn)# evi 10
OS10(config-evpn-evi)#
Supported
releases
10.4.2.0 or later
evpn
Enables the EVPN control plane for VXLAN.
Syntax
evpn
Parameters None
Default Not configured
Command mode CONFIGURATION
Usage information Enabling EVPN triggers BGP to advertise EVPN capability with AFI=25 and SAFI=70 to all BGP peers in an
autonomous system. The no version of this command disables EVPN on the switch.
Example
OS10(config)# evpn
OS10(config-evpn)#
Supported
releases
10.4.2.0 or later
rd
Configures the Route Distinguisher (RD) value that EVPN routes use.
Syntax
rd {A.B.C.D:[1-65535] | auto}
Parameters
A.B.C.D:
[1-65535]
Manually configure the RD with a 4-octet IPv4 address, then a 2-octet-number from 1 to
65535.
auto
Configure the RD to automatically generate.
Default Not configured
Command mode EVPN-EVI and EVPN-VRF
