• Write the post-ZTD script in bash or Python. Enter #!/bin/bash or #!/usr/bin/python as the first line in the script. The
default python interpreter in OS10 is 2.7.
Use only common Linux commands, such as curl, and common Python language constructs. OS10 only provides a limited set of Linux
packages and Python libraries.
• ZTD is disabled by default on automatically provisioned switch fabrics, such as Isilon backend, PowerEdge MX, and VxRail.
Cancel ZTD in progress
To exit ZTD mode and manually configure a switch by entering CLI commands, stop the ZTD process by entering the ztd cancel
command. You can enter ztd cancel only when ZTD is in a waiting state; that is, before it receives an answer from the DHCP server.
Otherwise, the command returns an error message; for example:
OS10# ztd cancel
% Error: ZTD cancel failed. ZTD process already started and cannot be cancelled at this stage.
Disable ZTD
To disable ZTD, enter the reload command. The switch reboots in ZTD disabled mode.
Re-enable ZTD
To automatically upgrade OS10 and/or activate new configuration settings, re-enable ZTD by rebooting the switch using the reload
ztd command. You are prompted to confirm the deletion of the startup configuration.
NOTE: To upgrade OS10 without losing the startup configuration, back up the startup configuration before ZTD runs
the provisioning script. Then use the backup startup configuration to restore the previous system configuration.
OS10# reload ztd
This action will remove startup-config [confirm yes/no]:
View ZTD status
OS10# show ztd-status
-----------------------------------
ZTD Status : disabled
ZTD State : completed
Protocol State : idle
Reason : ZTD process completed successfully at Mon Jul 16 19:31:57 2018
-----------------------------------
ZTD logs
ZTD generates log messages about its current status.
[os10:notify], %Dell EMC (OS10) %ZTD-IN-PROGRESS: Zero Touch Deployment
applying post configurations.
ZTD also generates failure messages.
[os10:notify], %Dell EMC (OS10) %ZTD-FAILED: Zero Touch Deployment failed to
download the image.
Troubleshoot configuration locked
When ZTD is enabled, the CLI configuration is locked. If you enter a CLI command, the error message configuration is locked
displays. To configure the switch, disable ZTD by entering the ztd cancel command.
OS10# configure terminal
% Error: ZTD is in progress(configuration is locked).
OS10# ztd cancel
