To import a CA server certificate:
1. Use the copy command to download an X.509v3 certificate created by a CA server using a secure method, such as HTTPS,
SCP, or SFTP. Copy the CA certificate to the local directory on the switch, such as home:// or usb://.
2. Use the crypto ca-cert install command to install the certificate. When you install a CA certificate, specify the local
path where the certificate is stored.
The switch verifies the certificate and installs it in an existing directory of trusted certificates in PEM format.
Install CA certificate
● Install a CA certificate in EXEC mode.
crypto ca-cert install ca-cert-filepath [filename]
○ ca-cert-filepath specifies the local path to the downloaded certificate; for example, home://CAcert.pem or
usb://CA-cert.pem.
○ filename specifies an optional filename that the certificate is stored under in the OS10 trust-store directory. Enter the
filename in the filename.crt format.
Example: Download and install CA certificate
OS10# copy scp:///tftpuser@10.11.178.103:/tftpboot/certs/Dell_rootCA1.pem home://
Dell_rootCA1.pem
password:
OS10# crypto ca-cert install home://Dell_rootCA1.pem
Processing certificate ...
Installed Root CA certificate
CommonName = Dell_rootCA1
IssuerName = Dell_rootCA1
Display CA server certificate
OS10# show crypto ca-certs
--------------------------------------
| Locally installed certificates |
--------------------------------------
Dell_rootCA1.crt
OS10# show crypto ca-certs Dell_rootCA1.crt
Certificate:
Data:
Version: 3 (0x2)
Serial Number:
95:48:23:17:76:9d:05:e1
Signature Algorithm: sha256WithRSAEncryption
Issuer: C = US, ST = California, L = Santa Clara, O = Dell EMC, OU = Networking,
CN = Dell_rootCA1
Validity
Not Before: Jul 25 18:21:50 2018 GMT
Not After : Jul 20 18:21:50 2038 GMT
Subject: C = US, ST = California, L = Santa Clara, O = Dell EMC, OU =
Networking, CN = Dell_rootCA1
Subject Public Key Info:
Public Key Algorithm: rsaEncryption
Public-Key: (4096 bit)
Modulus:
00:cd:9d:ca:10:6b:b1:54:81:10:92:42:9f:6a:cb:
49:51:9d:46:10:cb:67:08:2b:75:2a:62:40:80:a3:
f5:7d:58:67:f4:cc:c6:70:32:14:4c:f0:4d:cd:7e:
0d:5c:63:28:5e:6c:ad:9e:13:13:71:6d:9d:10:a9:
a1:d8:6b:bd:a3:a0:5a:11:19:87:4d:3d:08:6f:10:
03:df:70:89:5f:b7:56:49:32:57:9c:28:5e:43:7f:
ca:bc:41:c7:31:51:97:7f:73:b7:b0:c4:13:21:e6:
2c:4c:19:fd:35:0b:26:16:78:fc:c3:73:21:3a:06:
f6:ec:87:3f:9f:5e:3a:0c:23:5e:13:4c:9e:5a:70:
18:d4:ad:cb:cf:47:c1:c6:50:a0:49:df:a0:a6:47:
1e:13:19:49:9e:67:db:1c:c7:23:9e:37:3b:c7:0c:
cd:26:46:f6:c1:e1:93:64:29:81:9c:e9:a8:1d:29:
19:4c:8d:a4:a8:53:66:2b:b2:70:ff:ec:80:d4:87:
