any (Optional) Enter the keyword any to specify any source or destination IP address.
host ip-address (Optional) Enter the IPv6 address to use a host address only.
capture (Optional) Capture packets the filter processes.
count (Optional) Count packets the filter processes.
byte (Optional) Count bytes the filter processes.
dscp value (Optional) Permit a packet based on the DSCP values, from 0 to 63.
fragment (Optional) Use ACLs to control packet fragments.
log (Optional) Enables ACL logging. Information about packets that match an ACL rule are logged.
Default Not configured
Command Mode IPV6-ACL
Usage
Information
OS10 cannot count both packets and bytes; when you enter the count byte options, only bytes
increment. The no version of this command removes the filter.
Example
OS10(config)# ipv6 access-list ipv6test
OS10(conf-ipv6-acl)# permit udp any any capture session 1
Supported
Releases
10.2.0E or later
permit (MAC)
Configures a filter to allow packets with a specific MAC address.
Syntax
permit {nn:nn:nn:nn:nn:nn [00:00:00:00:00:00] | any} {nn:nn:nn:nn:nn:nn
[00:00:00:00:00:00] | any} [protocol-number | capture | count [byte] | cos
| vlan]
Parameters
nn:nn:nn:nn:nn:nn Enter the MAC address.
00:00:00:00:00:00 (Optional) Enter which bits in the MAC address must match. If you do not
enter a mask, a mask of 00:00:00:00:00:00 applies.
any (Optional) Set which routes are subject to the filter:
protocol-number Enter the MAC protocol number identified in the MAC header, from 600
to ffff.
capture (Optional) Enter the capture packets the filter processes.
count (Optional) Enter the count packets the filter processes.
byte (Optional) Enter the count bytes the filter processes.
cos (Optional) Enter the CoS value, from 0 to 7.
vlan (Optional) Enter the VLAN number, from 1 to 4093.
Default Not configured
Command Mode MAC-ACL
Usage
Information
OS10 cannot count both packets and bytes; when you enter the count byte options, only bytes
increment. The no version of this command removes the filter.
Example
OS10(config)# mac access-list macacl
OS10(conf-mac-acl)# permit 00:00:00:00:11:11 00:00:11:11:11:11 any cos 7
OS10(conf-mac-acl)# permit 00:00:00:00:11:11 00:00:11:11:11:11 any vlan 2
Supported
Releases
10.2.0E or later
Access Control Lists 1273
