Supported
Releases
10.3.0E or later
show debug dcbx
Displays the list of debug options that are enabled for DCBX.
Syntax
show debug dcbx
Parameters None
Command Mode EXEC
Usage
Information
None
Example
OS10# show debug dcbx
Dcbx debug settings:
debug dcbx all
no debug dcbx events interface mgmt
debug dcbx pdu in interface ethernet 1/1/1
Supported
Releases
10.5.1.0 or later
show lldp dcbx
Displays the DCBX configuration and PFC or ETS TLV status on an interface.
Syntax
show lldp dcbx {detail | ets detail | pfc detail | interface ethernet node/
slot/port[:subport] [ets detail | pfc detail]
Parameters
detail Display DCBX configuration information of all the interfaces in detail.
interface ethernet node/slot/port[:subport] Enter interface information.
ets detail Display the ETS TLV status and operation with DCBX peers.
pfc detail Display the PFC TLV status and operation with DCBX peers.
Default Not configured
Command Mode EXEC
Usage
Information
Enable DCBX before using this command. DCBX advertises all TLVs PFC, ETS Recommendation, ETS
Configuration, DCBXP, and basic TLVs by default.
NOTE: In the command output, the Is configuration source parameter always displays
False. Configuration source is the type of port role that is not supported.
Example (DCBX
detail)
OS10# show lldp dcbx detail | no-more
E-ETS Configuration TLV enabled e-ETS Configuration TLV disabled
R-ETS Recommendation TLV enabled r-ETS Recommendation TLV disabled
P-PFC Configuration TLV enabled p-PFC Configuration TLV disabled
F-Application priority for FCOE f-Application Priority for FCOE
enabled disabled
I-Application priority for iSCSI i-Application Priority for iSCSI
enabled disabled
------------------------------------------------------------------------
Interface ethernet1/1/1
Port Role is Manual
DCBX Operational Status is Disabled
Reason: Port Shutdown
Is Configuration Source? FALSE
Local DCBX Compatibility mode is AUTO
