If the IOM is not part of the SmartFabric, the system displays the following error:
Enter the Username for the Admin: admin
Password:
No Fabric found for specified nodes. Please recheck and issue this command again.
Output example when you use the module replacement command in the master IOM:
admin@MX9116N-A2:~$ sfs_node_replace.py JDB1XC2 68RRNK2
Enter the Username for the Admin: admin
Password:
% Total % Received % Xferd Average Speed Time Time Time Current
Dload Upload Total Spent Left Speed
100 142 100 89 100 53 646 384 --:--:-- --:--:-- --:--:-- 649
Node replacement work-flow is initiated, the node JDB1XC2 will reboot into Fabric mode.
After successful authentication, the system initiates the module replacement workflow and the new IOM reboots and is placed
in the SmartFabric Services mode.
Connect the new IOM
After the switch reboots to the SmartFabric Services mode, connect all the cables as originally connected to the failed IOM.
MX-IOM Hardware Replacement
Pre-requisites
NOTE: Prior to any IOM replacement activity, contact Dell technical support.
The firmware image should be uploaded to SCP server which is reachable across the network.
It is mandatory to have console access to connect to the IOM.
Before inserting the IOM into the chassis, ensure that you are able to monitor the boot up through console access. The image
needs to be uploaded onto SCP Server which is accessible from the IOM.
Console connection to the IOM is mandatory to mitigate any latency issues which could cause the user on remote console to
miss the output being shown in the console.
To replace the IOM hardware:
1. After the above prerequisite are met, insert the IOM into the chassis and monitor the GRUB menu to show up on the
console.
2. After the GRUB menu is visible, select the ONIE option and then select ONIE uninstall OS option.
3. After ONIE uninstall process is completed, IOM boots into ONIE install OS mode.
4. From the ONIE install OS mode, copy the image file from the file server and perform an ONIE image install.
View SmartFabric Services configuration
A SmartFabric is a network fabric that consists of physical resources, such as servers and switches and logical resources—
networks, templates, and uplinks. SmartFabric Services is an OS10 feature enabled on PowerEdge MX Ethernet I/O modules.
When you create a SmartFabric using the OpenManage Enterprise - Modular (OME-Modular) user interface, the switches
assigned to the fabric are automatically placed in SmartFabric mode. In SmartFabric mode, PowerEdge MX switches operate as
Layer 2 I/O aggregation devices with complete interoperability with all major network equipment vendors.
Use the OME-Modular interface to configure PowerEdge MX networking in SmartFabric mode. For more information, see:
PowerEdge MX Ethernet I/O modules
