○ video-conferencing — Voice conference network-policy application
○ video-signaling — Video signaling network-policy application
● vlan vlan-id — Enter the VLAN number for the selected application, from 1 to 4093.
● vlan-type — Enter the type of VLAN the application uses.
● tag — Enter a tagged VLAN number.
● untag — Enter an untagged VLAN number.
● priority priority — Enter the user priority set for the application.
● dscp dscp value — Enter the DSCP value set for the application.
Default Not configured
Command Mode CONFIGURATION
Usage
Information
You can create a maximum of 32 network policies and associate the LLDP-MED network policies to a
port.
Example
OS10(config)# lldp med network-policy 10 app voice vlan 10 vlan-type tag
priority 2 dscp 1
Supported
Releases
10.2.0E or later
lldp med network-policy (Interface)
Attaches or deletes an LLDP-MED network policy to or from an interface.
Syntax
lldp med network-policy {add | remove} number
Parameters
● add — Attach the network policy to an interface.
● remove — Remove the network policy from an interface.
● number — Enter a network policy index number, from 1 to 32.
Default Not configured
Command Mode INTERFACE
Usage
Information
Attach only one network policy for per interface.
Example
OS10(conf-if-eth1/1/5)# lldp med network-policy add 1
Supported
Release
10.2.0E or later
lldp med tlv-select
Configures the LLDP-MED TLV type to transmit or receive.
Syntax
lldp med tlv-select {network—policy | inventory}
Parameters
● network-policy — Enable or disable the port description TLV.
● inventory — Enable or disable the system TLV.
Default Enabled
Command Mode INTERFACE
Usage
Information
None
Example
OS10(conf-if-eth1/1/3)# lldp med tlv-select network-policy
