ethernet1/1/18 128.328 128 200000000 BLK 0 0 0000.0000.0000 0.0
ethernet1/1/19 128.332 128 200000000 BLK 0 0 0000.0000.0000 0.0
ethernet1/1/20 128.336 128 200000000 BLK 0 0 0000.0000.0000 0.0
ethernet1/1/21 128.340 128 200000000 BLK 0 0 0000.0000.0000 0.0
ethernet1/1/22 128.344 128 200000000 BLK 0 0 0000.0000.0000 0.0
ethernet1/1/23 128.348 128 200000000 BLK 0 0 0000.0000.0000 0.0
ethernet1/1/24 128.352 128 200000000 BLK 0 0 0000.0000.0000 0.0
ethernet1/1/25 128.356 128 200000000 BLK 0 0 0000.0000.0000 0.0
ethernet1/1/26 128.360 128 200000000 BLK 0 0 0000.0000.0000 0.0
ethernet1/1/27 128.364 128 200000000 BLK 0 0 0000.0000.0000 0.0
ethernet1/1/28 128.368 128 200000000 BLK 0 0 0000.0000.0000 0.0
ethernet1/1/29 128.372 128 200000000 BLK 0 0 0000.0000.0000 0.0
ethernet1/1/30 128.376 128 200000000 BLK 0 0 0000.0000.0000 0.0
ethernet1/1/31 128.380 128 200000000 BLK 0 0 0000.0000.0000 0.0
ethernet1/1/32 128.384 128 200000000 BLK 0 0 0000.0000.0000 0.0
Interface
Name Role PortID Prio Cost Sts Cost Link-type Edge
-------------------------------------------------------------------------
ethernet1/1/1 Disb 128.260 128 200000000 BLK 0 AUTO No
ethernet1/1/2 Disb 128.264 128 200000000 BLK 0 AUTO No
ethernet1/1/3 Disb 128.268 128 200000000 BLK 0 AUTO No
ethernet1/1/4 Disb 128.272 128 200000000 BLK 0 AUTO No
ethernet1/1/5:1 Disb 128.276 128 200000000 BLK 0 AUTO No
NOTE: In a VLAN setup that contains IOM fabrics running more than 100 VLANs, enable RSTP before deploying the
template from MSM.
Global parameters
The root bridge sets the values for forward-time, hello-time, and max-age, and overwrites the values set on other bridges
participating in the RSTP group.
NOTE:
Dell EMC recommends that only experienced network administrators change the RSTP group parameters. Poorly
planned modification of the RSTP parameters can negatively affect network performance.
Forward-time 15 seconds — Amount of time an interface waits in the Learning state before it transitions to the
Forwarding state.
Hello-time 2 seconds — Time interval in which the bridge sends RSTP BPDUs.
Max-age 20 seconds — Length of time the bridge maintains configuration information before it refreshes that
information by recomputing the RSTP topology.
Port cost Port cost values to set the path cost of the interface:
● 100-Mb/s Ethernet interfaces — 200000
● 1-Gigabit Ethernet interfaces — 20000
● 10-Gigabit Ethernet interfaces — 2000
● 40-Gigabit Ethernet interfaces — 500
● Port-channel with 100 Mb/s Ethernet interfaces — 200000
● Port-channel with 1-Gigabit Ethernet interfaces — 20000
● Port-channel with 10-Gigabit Ethernet interfaces — 2000
● Port-channel with 1x40Gigabit Ethernet interface — 500
● Port-channel with 2x40Gigabit Ethernet interfaces — 250
● Change the forward-time in CONFIGURATION mode, from 4 to 30, default 15.
spanning-tree rstp forward-time seconds
● Change the hello-time in CONFIGURATION mode, from 1 to 10, default 2. With large configurations, especially those
configurations with more ports, Dell EMC recommends increasing the hello-time.
spanning-tree rstp hello-time seconds
● Change the max-age in CONFIGURATION mode, from 6 to 40, default 20.
spanning-tree rstp max-age seconds
528
Layer 2
