Users Guide

BGP commands
activate
Enables the neighbor or peer group to be the current address-family identifier (AFI).
Syntax
activate
Parameters None
Default Not configured
Command Mode ROUTER-BGP-NEIGHBOR-AF
Usage
Information
This command exchanges IPv4 or IPv6 address family information with an IPv4, IPv6, and L2VPN
neighbor. IPv4 unicast Address family is enabled by default. To activate IPv6 address family for IPv6
neighbor, use the activate command. To deactivate IPv4 address family for IPv6 neighbor, use the no
activate command.
Example
OS10(conf-router-neighbor)# address-family ipv4 unicast
OS10(conf-router-bgp-neighbor-af)# activate
Supported
Releases
10.2.0E or later
add-path
Allows the system to advertise multiple paths for the same destination without replacing previous paths with new ones.
Syntax
add-path {both path count | receive | send path count}
Parameters
● both path count — Enter the number of paths to advertise to the peer, from 2 to 64.
● receive — Receive multiple paths from the peer.
● send path count — Enter the number of multiple paths to send multiple to the peer, from 2 to 64.
Default Not configured
Command Mode ROUTER-BGP-NEIGHBOR-AF
Usage
Information
Advertising multiple paths to peers for the same address prefix without replacing the existing path with a
new path reduces convergence times. The no version of this command disables the multiple path
advertisements for the same destination.
Example (IPv4)
OS10(conf-router-bgp-af)# add-path both 64
Example (IPv6)
OS10(conf-router-bgpv6-af)# add-path both 64
Example
(Receive)
OS10(conf-router-bgpv6-af)# add-path receive
Supported
Releases
10.2.0E or later
address-family
Enters Global Address Family Configuration mode for the IP address family.
Syntax
address-family {[ipv4 | ipv6] unicast}
Parameters
● ipv4 unicast — Enter an IPv4 unicast address family.
660 Layer 3
