Users Guide

Table Of Contents
Supported
Releases
10.2.0E or later
redistribute
Redistributes information from another routing protocol or routing instance to the OSPFv2 process.
Syntax
redistribute {bgp as-number| imported-ospf-routes | connected | static}
[route-map map-name]
Parameters
as-number Enter an autonomous number to redistribute BGP routing information throughout the
OSPF instance, from 1 to 4294967295.
connected Enter the information from the connected active routes on interfaces to redistribute.
static Enter the information from static routes on interfaces to redistribute.
route-map name Enter the name of a configured route-map.
Defaults Not configured
Command Mode ROUTER-OSPF
Usage
Information
When an OSPF redistributes, the process does not completely remove from the BGP configuration. The
no version of this command disables the redistribute configuration.
Example
OS10(config)# router ospf 10
OS10(conf-router-ospf-10)# redistribute bgp 4 route-map dell1
Example
(Connected)
OS10(config)# router ospf 10
OS10(conf-router-ospf-10)# redistribute connected route-map dell2
Supported
Releases
10.2.0E or later
router-id
Configures a fixed router ID for the OSPF process.
Syntax
router-id ip-address
Parameters ip-address Enter the IP address of the router as the router ID.
Default Not configured
Command Mode ROUTER-OSPF
Usage
Information
Configure an arbitrary value in the IP address format for each router. Each router ID must be unique. Use
the fixed router ID for the active OSPF router process. Changing the router ID brings down the existing
OSPF adjacency. The new router ID becomes effective immediately. The no version of this command
disables the router ID configuration.
Example
OS10(config)# router ospf 10
OS10(conf-router-ospf-10)# router-id 10.10.1.5
Supported
Releases
10.2.0E or later
router ospf
Enters Router OSPF mode and configures an OSPF instance.
Syntax
router ospf instance-number [vrf vrf-name]
758 Layer 3
