rx-ls-ack 0 rx-ls-ack-bytes 0
Transmit Statistics
tx-hello 1054 tx-hello-bytes 37944
tx-db-des 0 tx-db-des-bytes 0
tx-ls-req 0 tx-ls-req-bytes 0
tx-ls-upd 0 tx-ls-upd-bytes 0
tx-ls-ack 0 tx-ls-ack-bytes 0
Error packets (Receive statistics)
bad-src 0 dupe-id 0 hello-err 0
mtu-mismatch 0 nbr-ignored 0
resource-err 0 bad-lsa-len 0 lsa-bad-type 0
lsa-bad-len 0 lsa-bad-cksum 0
hello-tmr-mismatch 0 dead-ivl-mismatch 0
options-mismatch 0 nbr-admin-down 0 own-hello-drop 0
self-orig 0 wrong-length 0
version-mismatch 0 area-mismatch 0
Supported
Releases
10.4.0E(R1) or later
timers spf (OSPFv3)
Enables shortest path first (SPF) throttling to delay an SPF calculation when a topology change occurs.
Syntax
timers spf [start-time [hold-time [max-wait]]]
Parameters
● start-time — Sets the initial SPF delay in milliseconds, from 1 to 600000; default 1000.
● hold-time — Sets the additional hold time between two SPF calculations in milliseconds, from 1 to
600000; default 10000.
● max-wait — Sets the maximum wait time between two SPF calculations in milliseconds, from 1 to
600000; default 10000.
Default
● start-time — 1000 milliseconds
● hold-time — 10000 milliseconds
● max-wait — 10000 milliseconds
Command Mode ROUTER-OSPFv3
Usage
Information
OSPFv2 and OSPFv3 support SPF throttling. By default, SPF timers are disabled in an OSPF instance.
Use SPF throttling to delay SPF calculations during periods of network instability. In an OSPF network, a
topology change event triggers an SPF calculation after a specified start time. When the start timer
finishes, a hold time may delay the next SPF calculation for an additional time. When the hold timer is
running:
● Each time a topology change occurs, the SPF calculation delays for double the configured hold time
up to maximum wait time.
● If no topology change occur, an SPF calculation performs and the hold timer resets to its configured
value.
If you do not specify a start-time, hold-time, or max-wait value, the default values are used. The no
version of this command removes the configured SPF timers and disables SPF throttling in an OSPF
instance.
Example
OS10(config)# router ospfv3 100
OS10(config-router-ospfv3-100)# timers spf 1345 2324 9234
OS10(config-router-ospfv3-100)# do show ipv6 ospf
Routing Process ospfv3 100 with ID 129.240.244.107
SPF schedule delay 1345 msecs, Hold time between two SPFs 2324 msecs
Min LSA origination 5000 msec, Min LSA arrival 1000 msec
Min LSA hold time 0 msec, Max LSA wait time 0 msec
Number of area in this router is 1, normal 1 stub 0 nssa
Area (0.0.0.1)
Number of interface in this area is 1
SPF algorithm executed 2 times
