Inspiron 7415 2-in-1 Setup and Specifications Regulatory Model: P147G Regulatory Type: P147G001 March 2021 Rev.
Notes, cautions, and warnings NOTE: A NOTE indicates important information that helps you make better use of your product. CAUTION: A CAUTION indicates either potential damage to hardware or loss of data and tells you how to avoid the problem. WARNING: A WARNING indicates a potential for property damage, personal injury, or death. © 2021 Dell Inc. or its subsidiaries. All rights reserved. Dell, EMC, and other trademarks are trademarks of Dell Inc. or its subsidiaries.
Contents Chapter 1: Set up your Inspiron 7415 2-in-1................................................................................... 4 Chapter 2: Views of Inspiron 7415 2-in-1........................................................................................6 Right....................................................................................................................................................................................... 6 Left.................................................
1 Set up your Inspiron 7415 2-in-1 NOTE: The images in this document may differ from your computer depending on the configuration you ordered. 1. Connect the power adapter and press the power button. NOTE: The battery may go into power-saving mode during shipment to conserve charge on the battery. Ensure that the power adapter is connected to your computer when it is turned on for the first time. 2. Finish Windows setup. Follow the on-screen instructions to complete the setup.
Table 1. Locate Dell apps Resources Description SupportAssist SupportAssist proactively and predictively identifies hardware and software issues on your computer and automates the engagement process with Dell Technical support. It addresses performance and stabilization issues, prevents security threats, monitors and detects hardware failures. For more information, see SupportAssist for Home PCs User's Guide on www.dell.com/ serviceabilitytools.
2 Views of Inspiron 7415 2-in-1 Right 1. microSD-card slot Reads from and writes to the microSD card. The computer supports the following card types: ● microSecure Digital (microSD) ● microSecure Digital High Capacity (microSDHC) ● microSecure Digital Extended Capacity (microSDXC) 2. USB 3.2 Gen 1 port Connect peripherals such as external storage devices and printers. Provides data transfer speeds up to 5 Gbps. 3. Global headset jack Connect headphones or a headset (headphone and microphone combo).
Supports Power Delivery that enables two-way power supply between devices. Provides up to 5V/ 3A power output that enables faster charging. NOTE: A USB Type-C to DisplayPort adapter (sold separately) is required to connect a DisplayPort device. Top 1. Power button with optional fingerprint reader Press to turn on the computer if it is turned off, in sleep state, or in hibernate state.
Front 1. Left microphone Provides digital sound input for audio recording and voice calls. 2. Privacy shutter Slide the privacy shutter to cover the camera lens and protect your privacy when the camera is not in use. 3. Camera Enables you to video chat, capture photos, and record videos. 4. Camera-status light Turns on when the camera is in use. 5. Right microphone Provides digital sound input for audio recording and voice calls.
Bottom 1. Left speaker Provides audio output. 2. Service Tag label The Service Tag is a unique alphanumeric identifier that enables Dell service technicians to identify the hardware components in your computer and access warranty information. 3. Right speaker Provides audio output.
Tablet Stand Tent 10 Views of Inspiron 7415 2-in-1
3 Using the privacy shutter 1. Slide the privacy shutter to the left to access the camera lens. 2. Slide the privacy shutter to the right to cover the camera lens.
4 Specifications of Inspiron 7415 2-in-1 Dimensions and weight The following table lists the height, width, depth, and weight of your Inspiron 7415 2-in-1. Table 2. Dimensions and weight Description Values Height: Front height 16.32 mm (0.64 in.) Rear height 17.93 mm (0.70 in.) Width 321.50 mm (12.66 in.) Depth 211.35 mm (8.32 in.) Weight (maximum) 1.65 kg (3.63 lb) NOTE: The weight of your computer depends on the configuration ordered and manufacturing variability.
Chipset The following table lists the details of the chipset supported by your Inspiron 7415 2-in-1. Table 4. Chipset Description Values Chipset Integrated in the processor Processor AMD Ryzen 5/7 DRAM bus width 64-bit Flash EPROM 16 MB PCIe bus Up to Gen4 Operating system Your Inspiron 7415 2-in-1 supports the following operating systems: ● Windows 10 Professional (64-bit) ● Windows 10 Home (S mode) Memory The following table lists the memory specifications of your Inspiron 7415 2-in-1.
Table 6. External ports Description Values USB ports ● Two USB 3.2 Gen 1 ports ● One USB 3.2 Gen 1 Type-C with Power Delivery/ DisplayPort Audio port One global headset jack Video port/ports One HDMI 1.4b port Media-card reader One microSD-card slot Power-adapter port Type-C adapter Security-cable slot Not supported Internal slots The following table lists the internal slots of your Inspiron 7415 2-in-1. Table 7. Internal slots Description Values M.2 ● One M.
Audio The following table lists the audio specifications of your Inspiron 7415 2-in-1. Table 9. Audio specifications Description Values Audio controller Realtek ALC3204 Stereo conversion Supported Internal audio interface High-definition audio External audio interface Universal audio jack Number of speakers Two Internal-speaker amplifier Supported External volume controls Keyboard shortcut controls Speaker output: Average speaker output 2W Peak speaker output 2.
Table 11. Media-card reader specifications Description Values NOTE: The maximum capacity supported by the media-card reader varies depending on the standard of the media card installed in your computer. Keyboard The following table lists the keyboard specifications of your Inspiron 7415 2-in-1. Table 12.
Table 13. Camera specifications Description Values Diagonal viewing angle: 74.9 degrees Touchpad The following table lists the touchpad specifications of your Inspiron 7415 2-in-1. Table 14. Touchpad specifications Description Values Touchpad resolution: Horizontal 1229 Vertical 749 Touchpad dimensions: Horizontal 115 mm (4.53 in.) Vertical 70 mm (2.76 in.
Battery The following table lists the battery specifications of your Inspiron 7415 2-in-1. Table 16. Battery specifications Description Option one Option two Battery type 41 Wh, 3-cell polymer 54 Wh, 4-cell polymer Battery voltage 11.25 VDC 15 VDC Battery weight (maximum) 0.18 kg (0.40 lb) 0.23 kg (0.51 lb) Height 5.75 mm (0.23 in.) 5.75 mm (0.23 in.) Width 206.40 mm (8.13 in.) 272 mm (10.71 in.) Depth 82 mm (3.23 in.) 82 mm (3.23 in.
Table 17. Display specifications Description Values Diagonal 355.60 mm (14 in.) Display-panel native resolution 1920 x 1080 Luminance (typical) 212.50 nits Megapixels 2.073 Color gamut NTSC (45% typical) Pixels Per Inch (PPI) 157 Contrast ratio (min) 500:1 Response time (max) 35 ms Refresh rate 60 Hz Horizontal view angle 80 degrees Vertical view angle 80 degrees Pixel pitch 0.16 mm Power consumption (maximum) 3.
Table 19. Computer environment Description Operating Storage Shock (maximum) 110 G† 160 G† Altitude range -15.2 m to 3048 m (-49.87 ft to 10000 ft) -15.2 m to 10668 m (-49.87 ft to 35000 ft) * Measured using a random vibration spectrum that simulates user environment. † Measured using a 2 ms half-sine pulse when the hard drive is in use.
5 Keyboard shortcuts NOTE: Keyboard characters may differ depending on the keyboard language configuration. Keys used for shortcuts remain the same across all language configurations. Some keys on your keyboard have two symbols on them. These keys can be used to type alternate characters or to perform secondary functions. The symbol shown on the lower part of the key refers to the character that is typed out when the key is pressed.
Table 21.
6 Getting help and contacting Dell Self-help resources You can get information and help on Dell products and services using these self-help resources: Table 22. Self-help resources Self-help resources Resource location Information about Dell products and services www.dell.com My Dell app Tips Contact Support In Windows search, type Contact Support, and press Enter. Online help for operating system www.dell.
