114xxx | LDAP Feature for the RCSxxx
NOTE: It is possible to externally sever the Avocent authentication
association without performing these steps. Nonetheless, if an Avocent server
association has been created for user authentication, it must be expressly
removed via this procedure to permit LDAP authentication configuration to
proceed.
To enable LDAP Authentication:
1 Under User Access, select the LDAP tab, see Figure 5.3.
Figure 5.3: The LDAP Configuration Options Screen
2 Select one of the available LDAP Authentication modes in the Operational
Modes section.
3 Configuration options must be set to fully enable LDAP Authentication for
use. Each of the options are detailed in this chapter.
4 Click Save.
To disable LDAP authentication, select the Do Not Use LDAP option, and
click Save. All other options on the screen will be disabled; no editing of these
