122xxx | LDAP Feature for the RCSxxx
in Active Directory. If no values are found, the user is given no access to the
appliance or target devices
Group attribute
A username, password, and group query sent to the directory service for an
appliance and attached target devices when using Appliance query mode or for a
selected target device when using Target Device query mode. If a group is found
containing the user and appliance name, the user is given access to either the
appliance or target devices when using Appliance query mode. If a group is
found containing the user and target device IDs, the user is given access to the
selected target device when using Target Device query mode.
NOTE: Depending on the query mode selected, several of the configuration
items on this screen may be enabled or disabled according to their
applicability.
Group Configuration Parameters
There are several group configuration parameters available.
Group container
The group container specifies the OU created in Active Directory by the
administrator as the location for group objects. Group objects can contain users,
computers, contacts, and other groups, each assigned with a certain access level.
Group container mask
The group container mask defines the object type of the Group Container,
normally an OU. The default value is ou=%1.
Target device mask
The target device mask defines a search filter for the target device. The default
value is cn=%1.
Access control attribute
The access control attribute specifies the name of the attribute used when the
query modes are set to User Attribute or Group Attribute. The default attribute
