70xxx | Local and Remote Configurationxxx
Local Port UI Settings
To change how the local UI is invoked:
1 From the side navigation bar, select Ports - Local Port UI to open the
Local Port UI Settings screen.
2 Under the Invoke Local Port UI heading, select the checkbox next to one or
more of the listed methods.
3 Click Save.
You can turn on or turn off local port user interface authentication and choose a
user access level. If you turn on local port user interface authentication, you will
be required to log in to use the interface.
You can also select the keyboard language for the local port, scan mode time,
enable/disable the local port password and select a user preemption level. The
