76xxx | Local and Remote Configurationxxx
Setting Description
Virtual Media
Access per
SIP:Enable
VM/Disable VM
The Virtual Media Access per the SIP section lists
all virtual media SIPs. The list includes details
about each cable, including the option to enable
or disable virtual media for each cable.
Local Users
Local users can also determine the behavior of virtual media from the Local
Session screen. In addition to connecting and disconnecting a virtual media
session, you can configure the settings in the following table.
Table 3.7: Local Virtual Media Session Settings
Setting Description
CD ROM/
DVD ROM
Allows virtual media sessions to the first detected
CD-ROM or DVD-ROM (read-only) drives. Enable
this checkbox to establish a virtual media CD-ROM
or DVD-ROM connection to a target device.
Disable to end a virtual media CD-ROM or DVD-
ROM connection to a target device.
Mass Storage
Allows virtual media sessions to the first detected
mass storage drive. Enable this checkbox to
establish a virtual media mass storage connection
to a target device. Disable to end a virtual media
mass storage connection to a target device.
Reserved
Ensures that a virtual media connection can only
be accessed with your username and that no other
user can create a KVM connection to that target
device.
