86xxx | The Video Viewer Windowxxx
• Enable or disable Full Screen mode. When Full Screen mode is enabled, the
image adjusts to fit the desktop up to a size of 1600 x 1200 or 1680 x 1050
(widescreen). If the desktop has a higher resolution, the following occurs:
• The full-screen image is centered in the desktop, and the areas
surrounding the Video Viewer window are black.
• The menu and toolbar are locked so that they are visible at all times.
• Enable automatic, full or manual scaling of the session image:
• With full scaling, the desktop window remains fixed and the device
image scales to fit the window.
• With automatic scaling, the desktop window is sized to match the
resolution of the target device being viewed.
• With manual scaling, a drop-down menu of supported image scaling
resolutions is displayed.
• Change the color depth of the session image.
To align the mouse cursors:
Click the Align Local Cursor button in the Video Viewer window toolbar. The
local cursor should align with the cursor on the remote device.
NOTE: If cursors drift out of alignment, turn off mouse acceleration in the
attached device.
To refresh the screen, click the Refresh Image button in the Video Viewer
window, or select View - Refresh from the Video Viewer window menu. The
digitized video image is completely regenerated.
To enable Full Screen mode, click the Maximize button, or select View - Full
Screen from the Video Viewer window menu. The desktop window disappears
and only the accessed device desktop is visible. The screen resizes up to a
maximum of 1600 x 1200 or 1680 x 1050 (widescreen). If the desktop has a
higher resolution, then a black background surrounds the full screen image. The
floating toolbar appears.
