Installing the ExpressCard/Smart Card/PCMCIA Module
1. Attach the connector on the back of the ExpressCard/Smart Card/PCMCIA module to the marking on the connector
on the system board.
2. Tighten the screws to secure the ExpressCard/Smart Card/PCMCIA module.
3. Replace the palm rest.
4. Replace the CPU door.
5. Replace the keyboard trim.
6. Replace the keyboard.
7. Replace the optical drive.
8. Replace the back panel.
9. Replace the battery.
10. Follow the procedures in After Working Inside Your Computer.
Related Links
Removing the ExpressCard/Smart Card/PCMCIA Module
