Installing the Support Brackets
1. Slide the modem cable through the opening of the left-support bracket.
2. Place the left-support bracket in the original position.
3. Tighten the screws to secure the left-support bracket.
4. Secure the modem connector cable to its routing channel.
5. Connect the modem connector cable to the modem card.
6. Place the right-support bracket in the original position.
7. Tighten the screw to secure the right-support bracket.
8. Replace the modem card.
9. Replace the Bluetooth card.
10. Replace the audio board.
11. Replace the display assembly.
12. Replace the palm rest.
13. Replace the CPU door.
14. Replace the keyboard trim.
15. Replace the keyboard.
16. Replace the optical drive.
17. Replace the back panel.
18. Replace the battery.
19. Follow the procedures in After Working Inside Your Computer.
